Запчасти Case IH 2455 (8-22) - FOUR TINE GRAPPLE, FOR USE WITH 84 INCH HEAVY DUTY BUCKET

1

853501C1

FINGER

TINE - grapple

4шт.

413-1024

BOLT,Hex, 5/8" - 11 x 1-1/2", Gr 5

(Replaces bolt 271547) Hex, 5/8"-11 x 1 1/2", G5, Full Thd

12шт.

425-1010

NUT,5/8"-11, G5

(Replaces 124589) 5/8"-11, G5

12шт.

492-11062

BEARING WASHER,5/8"

WASHER, LOCK, (Replaces 121574) 5/8"

12шт.

2

853523C1

SUPPORT

- tine front

3шт.

413-1024

BOLT,Hex, 5/8" - 11 x 1-1/2", Gr 5

(Replaces bolt 271547) Hex, 5/8"-11 x 1 1/2", G5, Full Thd

2шт.

413-1028

BOLT,Hex, 5/8" - 11 x 1-3/4", Gr 5

- hex, 5/8 NC x 1-3/4 inch (replaces 271548)

2шт.

425-1010

NUT,5/8"-11, G5

(Replaces 124589) 5/8"-11, G5

2шт.

492-11062

BEARING WASHER,5/8"

WASHER, LOCK, (Replaces 121574) 5/8"

2шт.

3

853503C1

SUPPORT

- tine rear LH

2шт.

4

853504C1

SUPPORT

- tine rear RH

2шт.

413-1020

BOLT,Hex, 5/8" - 11 x 1-1/4", Gr 5

(Replaces 271546) Hex, 5/8"-11 x 1 1/4", G5, Full Thd

4шт.

413-1024

BOLT,Hex, 5/8" - 11 x 1-1/2", Gr 5

(Replaces bolt 271547) Hex, 5/8"-11 x 1 1/2", G5, Full Thd

4шт.

425-1010

NUT,5/8"-11, G5

(Replaces 124589) 5/8"-11, G5

8шт.

492-11062

BEARING WASHER,5/8"

WASHER, LOCK, (Replaces 121574) 5/8"

8шт.

5

853505C1

ANGLE

- tine support

2шт.

413-1020

BOLT,Hex, 5/8" - 11 x 1-1/4", Gr 5

(Replaces 271546) Hex, 5/8"-11 x 1 1/4", G5, Full Thd

4шт.

425-1010

NUT,5/8"-11, G5

(Replaces 124589) 5/8"-11, G5

4шт.

492-11062

BEARING WASHER,5/8"

WASHER, LOCK, (Replaces 121574) 5/8"

4шт.

6

853513C1

SHAFT

ROCKSHAFT ASSEMBLY - tine

1шт.

7

853508C1

SUPPORT

ASSEMBLY - pivot LH

1шт.

8

853509C1

SUPPORT

ASSEMBLY - pivot RH

1шт.

413-816

BOLT,Hex, 1/2" - 13 x 1", Gr 5

(Replaces 180173) Hex, 1/2"-13 x 1", G5, Full Thd

4шт.

413-820

BOLT,Hex, 1/2" - 13 x 1-1/4", Gr 5

- hex, 1/2 NC x 1-1/4 inch (replaces 180175)

4шт.

425-108

NUT,1/2" - 13, Gr 5

NUT, , Hex (Replaces 120378) 1/2"-13, G5

8шт.

80679

LOCK WASHER,1/20.507 CST ZND

WASHER, LOCK, (Replaces washer 120384) 1/2"

8шт.

9

853524C1

SUPPORT

- base lower

2шт.

413-824

BOLT,Hex, 1/2" - 13 x 1-1/2", Gr 5

(Replaces 180177) Hex, 1/2"-13 x 1 1/2", G5, Full Thd

4шт.

425-108

NUT,1/2" - 13, Gr 5

NUT, , Hex (Replaces 120378) 1/2"-13, G5

4шт.

80679

LOCK WASHER,1/20.507 CST ZND

WASHER, LOCK, (Replaces washer 120384) 1/2"

4шт.

495-81287

WASHER,13.49mm ID x 31.75mm OD x 3.4mm Thk

- flat, 17/32 x 1-1/4 x 7/64 inch (replaces 20601R1)

4шт.

10

219-1

LUBE NIPPLE,1/8" - 27 NPTF

FITTING - grease, straight, 1/8 PT x 21/32 inch (replaces 109461)

2шт.
