Запчасти Case IH 1550 (B-27) - 400 BLADE ATTACHMENT

473977R1

BOLT

BOLT, breakaway spg eye

2шт.

20033R1

LOCK NUT

LK-NUT, 5/8"

2шт.

473407R91

BRACKET, blade LH

1шт.

271724

PIN,Hex, 5/8" - 11 x 2 1/4", Gr 5

5/8 x 2-1/4"

1шт.

124589

BALL STUD,Hex, 5/8" - 11 x 2", Gr 5

5/8"

1шт.

492-11062

BEARING WASHER,5/8"

WASHER, LOCK, 5/8"

1шт.

18866R1

SCREW,1" x 2 1/4"

BOLT, 1 x 2-1/4"

1шт.

18521R1

LOCK NUT,1"-14, G8

LK-NUT, 1"

1шт.

23471S

WASHER

25/32 x 1-1/2 x 7 ga plain

2шт.

473408R91

BRACKET, blade RH

1шт.

413-1036

BOLT,Hex, 5/8" - 11 x 2-1/4", Gr 5

5/8 x 2-1/4"

1шт.

280374

NUT,Hex, 5/8" - 11, Gr 5

5/8"

1шт.

492-11062

BEARING WASHER,5/8"

WASHER, LOCK, 5/8"

1шт.

18866R1

SCREW,1" x 2 1/4"

BOLT, 1 x 2-1/4"

1шт.

18521R1

LOCK NUT,1"-14, G8

LK-NUT, 1"

1шт.

23471S

WASHER

25/32 x 1-1/2 x 7 ga plain

2шт.

472495R1

EDGE, 72" mouldboard cutting

1шт.

465567R1

CARRIAGE BOLT,Sht Sq Nk, 1/2" - 13 x 1 1/2", Gr 5

BOLT, 1/2 x 1-1/2" crg

9шт.

120378

NUT,Hex, 1/2" - 13, Gr 5

NUT, 1/2"-13, G5

9шт.

120384

WASHER,1/2"

LOCK, 1/2"

9шт.

472502R1

EDGE, 78" mouldboard cutting

1шт.

465567R1

CARRIAGE BOLT,Sht Sq Nk, 1/2" - 13 x 1 1/2", Gr 5

BOLT, 1/2 x 1-1/2" crg

9шт.

120378

NUT,Hex, 1/2" - 13, Gr 5

NUT, 1/2"-13, G5

9шт.

120384

WASHER,1/2"

LOCK, 1/2"

9шт.

473395R91

FRAME, blade main

1шт.

189314

BOLT,Hex, 1/2" - 13 x 4 3/4", Gr 5

1/2 x 4-3/4"

2шт.

19676R1

LOCK NUT,1/2"-13, GB

LK-NUT, 1/2"

2шт.

446294

WASHER, 1-5/16 x 2-3/4 x .165"

1шт.

472456R12

FRAME, pivot

1шт.

472488R91

MOULDBOARD, 400 blade 72"

1шт.

472498R91

MOULDBOARD, 400 blade 78"

1шт.

16719W

NUT, 1-1/4"-NF slt

1шт.

119180

C-PIN, 7/32 x 1-7/8"

1шт.

472448R2

PIN, angling

1шт.

495-11094

WASHER,7/8", SAE

15/16 x 1-3/4 x .134"

2шт.

103389

SPLIT PIN/SAFETY PIN,1/8" x 2"

Pin, Split (Cotter), 1/8" x 2"

2шт.

473399R1

RETAINER, pivot pin

1шт.

181697

1/2-NF x 1-1/8"

1шт.

19332R1

NUT,1/2"-20, GC

1/2"-NF nylon insert

1шт.

18656R1

BOLT,Hex, 1/4" - 20 x 1 1/4", Gr 2

1/4-NF x 1-1/4" type 1

1шт.

18306R1

LOCK NUT,1/4"-20, GB

NUT, 1/4"-NF nylon insert

1шт.

472458R1

ROD, pivot

1шт.

108560

C-PIN, 7/32 x 1-1/2"

2шт.

472496R1

SHOE, skid

2шт.

20088R1

BOLT, 7/8 x 7" type 1 dld

2шт.

427643

SLOTTED NUT,7/8"-9, G5

NUT, 7/8" slt

2шт.

446266

WASHER,7/8" x 2" x .165"

15/16 x 2 x .165"

16шт.

125637

COTTER PIN,1/8" x 2"

PIN, SPLIT (COTTER), 1/8" x 2"

2шт.

PO139

SPRING, angling pin

1шт.

472459R1

SPRING, breakaway

2шт.
