Запчасти Case IH 85 (A-15) - HAMMERMILL SHAFT UNIT

1

475733R91

PULLEY

12 groove V-belt

1шт.

2

475763R1

KEY

3/8 x 6-1/4 sq gib head tapered

1шт.

3

475764R91

BEARING ASSY,5" OD x 2.38"

BEARING, pillow block ball, 2 used up to 1965, 1 used 1965 and since

1шт.

413-1036

BOLT,Hex, 5/8" - 11 x 2-1/4", Gr 5

5/8-11 x 2-1/4 hex-hd mach

2шт.

280374

NUT,Hex, 5/8" - 11, Gr 5

5/8-11 hex

2шт.

492-11062

BEARING WASHER,5/8"

WASHER, LOCK, 5/8"

2шт.

130998

WASHER,9/16"

5/8 x 1-1/2 x 12 ga

2шт.

4

127743

LUBE NIPPLE,65 Degree, 1/8" NPT x 1.20" lg

FITTING, 1/8-27 PTF 65 deg angle lub

2шт.

5

475765R91

ROTOR

SHAFT ASSY, order 487857R91

1шт.

6

576485R1

LOCK PIN,1/4" x 1 1/4", Slotted

8шт.

7

475766R1

ROD

3/4 OD x 18 in.

4шт.

8

555696R1

SPACER,3/4" Pipe x 5/8"

3/4 x 5/8 pipe

36шт.

9

C23767

SPACER

3/4 x 1-1/4 pipe

18шт.

10

476672R91

HAMMER

2шт.

10

491393R91

PACKAGE

HAMMERS, set of 36

1шт.

11

Q87

KEY,3/8" Sq x 1 1/2", Par

3/8 x 1-1/4 sq parallel

1шт.

12

475768R1

FAN

blower

1шт.

IH219779

NUT

1-1/2 hex jam

1шт.

13

485936R91

BEARING CARRIER

BEARING ASSY, pillow block spherical, 1965 and since

1шт.

413-1036

BOLT,Hex, 5/8" - 11 x 2-1/4", Gr 5

5/8-11 x 2-1/4 hex-hd mach

2шт.

280374

NUT,Hex, 5/8" - 11, Gr 5

5/8-11 hex

2шт.

492-11062

BEARING WASHER,5/8"

WASHER, LOCK, 5/8"

2шт.

130998

WASHER,9/16"

5/8 x 1-1/2 x 12 ga

2шт.
