Артикул
Название
Примечание
Количество
1
13021
HOSE CLAMP,12.7mm - 23.1mm, Worm Gear
2шт.
2
15734
SCREW,Hex Socket, 1/2" - 13 x 1-3/4"
2шт.
6
129274
TEE,9/16" - 18 JIC x 9/16" - 18 JIC x 9/16" - 18 JIC
1шт.
7
265808
TEE,3/4" - 16 JIC x 3/4" - 16 JIC x 3/4" - 16 ORB
1шт.
8
300442
HEX SOC SCREW,M10 x 30mm, Cl 8.8
10шт.
9
87711337
COUPLING,19T, 1-1/8" ID
1шт.
10
87655042
SPECIAL WASHER,8.8mm ID x 17.5mm OD x 2.2mm Thk
2шт.
11
87329785
ELBOW,90 Degree, 1-1/16" - 12 ORB x 3/4" - 16 JIC
1шт.
12
9617891
ELBOW,90 Degree, 3/4" - 16 JIC x 7/8" - 14 ORB
1шт.
13
9804261
BOLT,Hex, M10 x 25mm, Cl 8.8, Full Thd
2шт.
15
9824642
BOLT,M12 x 1.75 x 42.68mm, Cl 10.9
2шт.
16
9840535
HYD CONNECTOR,1-3/16" - 12 ORFS x 1-1/16" - 12 ORB
4шт.
17
16044321
BOLT,M8 x 1.25 x 55mm, Cl 8.8
3шт.
18
87314487
HYD CONNECTOR,7/16" - 20 ORB x 1/2" Hose Barb
1шт.
19
86637955
WASHER,0.66" ID x 1.25" OD x 0.24" Thk
0.656" ID x 1.25" OD
2шт.
20
47659211
Flywheel
COVER
1шт.
21
86625255
WASHER,13.3mm ID x 24.5mm OD x 3mm Thk
1шт.
23
84288343
FLEXIBLE HOSE,9.53mm ID x 750mm L, SAE 100R17
EH Control to Brake
1шт.
24
84356607
Charge Supply
HYDRAULIC HOSE,9.53mm ID x 364mm L, SAE 100R17
1шт.
25
84356613
Charge Supply Brake
HYDRAULIC HOSE,9.53mm ID x 552mm L, SAE 100R17
1шт.
26
84356615
Charge Supply Loader Valve
HYDRAULIC HOSE,9.53mm ID x 402mm L, SAE 100R17
1шт.
27
84356618
Pump to Brake
HYDRAULIC HOSE,9.53mm ID x 592mm L, SAE 100R17
1шт.
28
84356619
EHF Drain
HYDRAULIC HOSE,15.88mm ID x 335mm L
1шт.
29
84373394
Aux to EH Aux Drain, Years: -20-NOV-15
HOSE,12.7mm ID x 410mm L
1шт.
29
47919061
HOSE,16mm ID x 535mm L
Aux to EH Aux Drain, Start Serial: 21-NOV-2015
1шт.
31
86513020
TEE,9/16" - 18 ORB x 9/16" - 18 JIC x 9/16" - 18 JIC
1шт.
32
84387079
EHF Pump Drain
HYD TUBE,12.7mm OD
1шт.
33
84419203
P1 to P2
HYD TUBE,12.7mm OD
1шт.
34
84419205
EH Control to Brake
HOSE ASSY.,9.53mm ID x 780.8mm L, SAE 100R1
1шт.
35
84473278
-10ORB x -10Bead x M10
FITTING,7/8"-14 ORB x 15.88mm OD Bead x M10 x 1.0
1шт.
36
84549542
CLAMP,20.5mm - 24mm, Hose
2шт.
37
84549585
Pump Support
MOUNTING PLATE
1шт.
38
84560846
HOSE ASSY.,19.05mm ID x 677mm L, SAE 100R19
Loop
1шт.
39
84560847
HOSE ASSY.,19.05mm ID x 957mm L, SAE 100R19
Loop
1шт.
40
84560849
HOSE ASSY.,19.05mm ID x 1572mm L, SAE 100R19
Loop
1шт.
41
84560851
HOSE ASSY.,19.05mm ID x 1647mm L, SAE 100R19
Loop
1шт.
44
86512936
ELBOW,9/16" - 18 JIC x 7/16" - 20 ORB
1шт.
Выбрано товаров: 45
