Артикул
Название
Примечание
Количество
1
84371087
Tilt Gray
HOOD
1шт.
2
84354590
COVER PLATE
1шт.
3
84354589
COVER PLATE
1шт.
4
84285339
SELF-TAP SCREW,Hex, M8 x 1.25 x 15mm
M8 X 15
10шт.
5
84420534
Hood Stop
STOP
2шт.
6
84313073
Angle, Hood Lock Tab Tan
LOCKING TAB
1шт.
7
9804258
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
2шт.
9
84201350
Panel, W Rear Deck Large Gray
PANEL
1шт.
10
86512444
CARRIAGE BOLT,M8 x 1.25 x 40mm, Full Thd, Cl 8.8
2шт.
11
84299800
Gray
COVER PLATE
1шт.
12
87030529
SELF-TAP SCREW,HWH, 3/8" - 16 x 7/8"
6шт.
13
647429
DRAIN PLUG,Sq Soc HD, 1/2" - 14, NPTF
Pipe
2шт.
14
236622
PLUG,3/8" - 18 NPT
Pipe
2шт.
15
84299809
Plumbing Access Cover
COVER PLATE
1шт.
16
87429698
SPACER
Hood
2шт.
17
259905A1
SPACER
2шт.
18
120039
CARRIAGE BOLT,M8 x 1.25 x 54.8mm, Cl 8.8
2шт.
19
84356838
MOUNTING PLATE
1шт.
20
400473A1
CYLINDER ASSY.,186.84mm L, Extended, 148.74mm L, Compressed
Spring Cylinder...Hood Assist
2шт.
21
189609A1
BALL STUD,M8 x 1.25
4шт.
22
86625263
WASHER,9mm ID x 20mm OD x 1.6mm Thk
2шт.
23
229197A1
SQUARE NUT,M8 x 1.25, Cl 8
Square
1шт.
25
406256A1
HANDLE
Rear Hood (Not Shown)
1шт.
26
86511827
SCREW,Phillips Drive, Pan HD, M5 x 20mm, Cl 4.8
(Not Shown)
2шт.
28
86625264
LOCK WASHER,Ext Tooth, M5
(Not Shown)
2шт.
Выбрано товаров: 28
