Запчасти Case IH TR310 (88.100.55[16]) - DIA KIT, HANDLE - 300 LH - NO 2ND AUX - MECHANICAL (88) - ACCESSORIES

Схема запчастей Case IH TR310 - (88.100.55[16]) - DIA KIT, HANDLE - 300 LH - NO 2ND AUX - MECHANICAL (88) - ACCESSORIES

Артикул

Название

Примечание

Количество

1

47542206

KIT

LH Handle - Level 300, Case, No 2nd Aux, Mechanical, Incl 2 - 14

1шт.

2

47542204

INSTRUCTION

Sheet

1шт.

3

263117

CABLE TIE,292.1mm L, Nylon, Black

Nylon

1шт.

4

9706685

NUT,M12 x 1.75, Cl 8

1шт.

5

84279937

PLUG,Apex, 2.80mm

11шт.

6

84396068

LH, Level 300, No 2nd Aux

HANDLE GRIP

1шт.

7

84396167

DECAL

LH, Level 350, No 2nd Aux

1шт.

8

87382925

WIRE CONNECTOR,Female, 10 Cavities

1шт.

9

87382927

ELEC CONNECTOR,Male, 14 Cavities

1шт.

10

87668737

CABLE TIE,203.2mm L, Nylon, Black

Nylon

3шт.

11

87689636

PLUG,Red, Taxi Seal Connector Cavity

Cable Cavity

1шт.

12

87689643

CLIP,4.8mm ID

Black, Secondary Lock

1шт.

13

87697724

ELEC CONNECTOR,Female, 4 Cavities

1шт.

14

378884A2

STRAP,254mm L

Nylon

3шт.

Выбрано товаров: 14
