Артикул
Название
Примечание
Количество
1
87655042
SPECIAL WASHER,8.8mm ID x 17.5mm OD x 2.2mm Thk
5шт.
2
16044321
BOLT,M8 x 1.25 x 55mm, Cl 8.8
3шт.
5
84288343
FLEXIBLE HOSE,9.53mm ID x 750mm L, SAE 100R17
1шт.
6
86512936
ELBOW,9/16" - 18 JIC x 7/16" - 20 ORB
Incl 47
1шт.
8
84273629
FITTING,1-1/16" - 12 ORB x M10 x 1 x 5/8" Hose Barb
Incl 46
1шт.
9
87711337
COUPLING,19T, 1-1/8" ID
Drive Star
1шт.
11
9790095
BOLT,1/2" - 13 x 1-3/4", Gr 8
2шт.
12
86625255
WASHER,13.3mm ID x 24.5mm OD x 3mm Thk
2шт.
13
87670
BOLT,1/2" - 13 x 1-1/4", Full Thd, Gr 5
2шт.
15
47845789
EH Brake Charge
HOSE,10mm ID x 420mm L
1шт.
16
84299736
FLEXIBLE HOSE,9.53mm ID x 512mm L, SAE 100R17
EH LV Interlock
1шт.
17
84273646
Pump Drain
HOSE,15.88mm ID x 304.8mm L
1шт.
18
84309599
FLEXIBLE HOSE,9.53mm ID x 780mm L, SAE 100R17
EH Brake
1шт.
19
86513020
TEE,9/16" - 18 ORB x 9/16" - 18 JIC x 9/16" - 18 JIC
Incl 48
1шт.
20
9804265
FLANGE BOLT,Hex, M10 x 60mm, Cl 8.8
3шт.
21
84349300
RIGID TUBE,12.7mm OD
EH Charge Supply
1шт.
22
47659227
COVER
Flywheel
1шт.
23
300442
HEX SOC SCREW,M10 x 30mm, Cl 8.8
9шт.
25
47889297
RH CTL, Drive Motor
HYD TUBE
1шт.
26
47889299
RH CTL, Drive Motor
HYD TUBE
1шт.
27
47889524
LH CTL, Drive Motor
HYD TUBE
1шт.
28
47889526
LH CTL, Drive Motor
HYD TUBE
1шт.
29
47926580
HOSE,19mm ID x 670mm L, SAE100R19
1шт.
30
47926578
HOSE,19mm ID x 565mm L, SAE100R19
1шт.
31
47926582
HOSE,19mm ID x 760mm L, SAE100R19
1шт.
32
47926584
HOSE,19mm ID x 645mm L, SAE100R19
1шт.
33
1546028C1
CLAMP,25.4mm ID x 82mm L
Dual
2шт.
34
47893882
Clamp Mounting
PLATE
1шт.
35
86511843
BOLT,Hex Flng, M8 x 1.25 x 60mm, Cl 8.8
2шт.
36
257859A1
PLATE, SPACER,31.8mm W x 68mm L x 4.76mm Thk
2шт.
37
120062
BOLT,Hex, M8 x 70mm, Cl 8.8
1шт.
38
229197A1
SQUARE NUT,M8 x 1.25, Cl 8
2шт.
39
225529A1
CLAMP,Dual, 25.4mm ID
1шт.
40
47895194
Clamp Mounting
BRACKET
1шт.
41
86511841
BOLT,Flng, M8 x 1.25 x 16mm, Full Thd, Cl 8.8
1шт.
42
9846848
90 ELBOW,1-3/16"-12 ORFS x 1-1/16"-12 ORB
Incl 45
2шт.
43
87661865
HYD CONNECTOR,1-3/16" - 12 ORFS x 1-1/16" - 12 ORB
Incl 45
2шт.
44
84549542
CLAMP,20.5mm - 24mm, Hose
2шт.
47
165202
O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro
1шт.
Выбрано товаров: 48
