(90.108.AC[01]) - DECALS (TR270)

Запчасти Case IH TR270 (90.108.AC[01]) - DECALS (TR270) (90) - PLATFORM, CAB, BODYWORK AND DECALS

Схема запчастей Case IH TR270 - (90.108.AC[01]) - DECALS (TR270) (90) - PLATFORM, CAB, BODYWORK AND DECALS
5
home
4
3
6
2
1
7
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

87673472

DECAL

Grease Spring Warning

2шт.

2

84367429

Crush Hazard

WARNING DECAL

1шт.

3

87482464

DECAL

Low Sulfur Fuel

1шт.

4

84367585

Lubrication, Radial

DECAL

1шт.

5

84350666

Operating Capacity

DECAL

1шт.

6

84357636

DECAL,53mm OD, Gray

Plug

1шт.

7

299274A2

COVER,35mm OD

Lexan, Years: -04-OCT-16

4шт.
