1
87546977
PUMP,46 CC
A22; See Figure 06-47 - 06-53
1шт.
1
87546977R
Remanufactured Hydraulic Pump
REMAN-HYD PUMP
1шт.
1
87546977C
Return Number
CORE-HYDRAULIC PUMP
1шт.
2
86625255
WASHER,13.3mm ID x 24.5mm OD x 3mm Thk
2шт.
3
87670
BOLT,1/2" - 13 x 1-1/4", Full Thd, Gr 5
2шт.
4
128830
90 ELBOW,3/4" - 16 JIC x 3/4" - 16 ORB
Incl. 5
1шт.
5
128825
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
1шт.
6
87554297
HYD TUBE,10.2 mm ID x 12.7 mm OD x 147, 99.2 mm L
Tube, Tandem Pump Supply
1шт.
7
87604074
ADAPTER
6FJ x 6MJ W/ 1.2 Orifice
2шт.
8
87546979
ADAPTER
Incl 9, 10
2шт.
9
9617873
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
1шт.
10
165202
O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro
1шт.
11
76349
PLUG,9/16" - 18 ORB
Incl. 12; If Used
2шт.
12
9617873
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
If Used
1шт.
13
128818
UNION,3/4" - 16 ORB x 3/4" - 16 JIC
Incl 14; If Used
1шт.
13
81827427
HYD CONNECTOR,3/4" - 16 JIC x 3/4" - 16 ORB
Incl 14
1шт.
14
128825
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
1шт.
15
76350
HYD CONNECTOR,9/16" - 18 ORB x 9/16" - 18 JIC
Incl 16
1шт.
16
9617873
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
1шт.
17
87571937
ADAPTER
Incl 18, 19
1шт.
18
167266
O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro
1шт.
19
167269
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
1шт.
20
87556906
BOLT,Hex, M14 x 70mm, Cl 10.9
2шт.
21
87016615
WASHER,15.3mm ID x 28.5mm OD x 3mm Thk
2шт.
22
87637186
NUT
M14 Class 10 ZND
2шт.
23
87564723
WASHER,15.3mm ID x 28.5mm OD x 6mm Thk
Washer, 15.3 x 28.5 x 6 HTS ZND
4шт.
24
9846848
90 ELBOW,1-3/16"-12 ORFS x 1-1/16"-12 ORB
Incl. 25, 26
1шт.
25
9991976
O-RING,0.07" Thk x 0.739" ID, -18, Cl 6, 90 Duro
1шт.
26
167266
O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro
1шт.
27
86526
ELBOW,90 Degree, 37 Degree 9/16" - 18 JIC x 9/16" - 18 ORB
Incl 28
1шт.
28
9617873
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
1шт.
29
9840535
HYD CONNECTOR,1-3/16" - 12 ORFS x 1-1/16" - 12 ORB
Incl. 30, 31
3шт.
30
9991976
O-RING,0.07" Thk x 0.739" ID, -18, Cl 6, 90 Duro
1шт.
31
167266
O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro
1шт.
