Запчасти Case IH CM109 (05.000.03) - DEALER SUGGESTED STOCKING LIST (05) - SERVICE & MAINTENANCE

1

84230728

BRAKE PAD

2шт.

2

84230726

BRAKE BAND

2шт.

3

84230724

BRONZE BUSHING

2шт.

4

36727

OIL SEAL,38.1mm ID x 59.28mm OD x 13.11mm Thk

2шт.

5

36726

BEARING CONE,31.75mm ID x 16.76mm W

2шт.

6

36723

BEARING CUP,59.16mm OD x 11.81mm W

2шт.

7

84230735

HUB

1шт.

8

36725

BEARING CUP,45.26mm OD x 12.06mm W

2шт.

9

36724

BEARING CONE,19.07mm ID x 16.64mm W

2шт.

10

651194R1

CAP

2шт.

11

84230711

PILLOW BLOCK

2шт.

12

84230718

PIN

2шт.

13

84230719

CLIP

Clip. Conveyor Belt Lacing

2шт.

14

84230906

BALL BEARING

2шт.

15

84230908

COLLAR

2шт.

16

84230913

BEARING HOUSING

2шт.

17

84230932

KIT

Dutchman Repair, Used To Repair Pickup Belt

1шт.

18

84230929

CONVEYOR BELT

1шт.

19

84230933

TOOTH

12шт.

20

84230934

BOLT

24шт.

21

86562216

NUT,Keps, w/LW,1/4"-20

24шт.

22

97859C1

SEAL

2шт.

23

536264

BEARING CONE,26.98mm ID x 14.73mm W

4шт.

24

132709

BEARING CUP,50.29mm OD x 10.67mm W

4шт.

25

74771C1

CAP

2шт.

26

84230690

JACK

1шт.

27

84230687

HANDLE

1шт.

28

70203C2

HYDRAULIC OIL FILTER

1шт.

29

84292739

KIT

Mainframe Conveyor Belt Repair

1шт.
