Запчасти Case IH DRAPER (B-07) - DRAPER HEADER (15) - CROP CONDITIONING

1

829299C1

SPROCKET ASSY.

SPROCKET, 11 T reel drive, for connecting parts refer to reel drive

1шт.

19790R1

PIN,5/16" x 1 1/4", Coiled

1шт.

2

829349C1

SHAFT

header drive counter 12-1/2 ft

1шт.

2

829350C1

SHAFT

header drive counter 14-1/2 ft

1шт.

2

829351C2

SHAFT

header drive counter 16-1/2 ft

1шт.

2

831294C1

SHAFT

header drive counter 19-1/2 ft

1шт.

3

PULLEY, knife drive, for service parts refer to knife drive

1шт.

4

21753R1

WASHER

.781 x 1.500 x .054

3шт.

5

565672R91

BALL BEARING,1.25" ID x 72 mm OD x 1.53125"

countershaft, 3 used 19-1/2 ft

2шт.

6

455104R11

COLLAR

W/SET SCREW, locking, 3 used 19-1/2 ft

2шт.

102592

SET SCREW,Hex Skt, 3/8" - 16 x 3/8"

SCREW, 3/8-16 x 3/8 cup-pt hdls hex soc set, 3 used 19-1/2 ft

2шт.

7

617863R1

FLANGED BEARING

RETAINER, bearing, 6 used 19-1/2 ft

4шт.

495967R1

CARRIAGE BOLT,Short NK, 3/8"-16 x 1", G5, Full Thd

BOLT, 3/8-16 x 1 carriage, 9 used 19-1/2 ft

6шт.

120377

NUT,3/8" - 16, Gr 5

9 used 19-1/2 ft 3/8"-16, G5

6шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, , 9 used 19-1/2 ft 3/8"

6шт.

8

829353C1

DRIVE SPROCKET

SPROCKET ASSY, 23T roller drive shaft

1шт.

88907

WOODRUFF KEY,#B, 5/16" x 1", HT

5/16 x 1 Woodruff

1шт.

115321

SET SCREW,Hex Skt, 5/16"-18 x 5/16"

SCREW, 5/16-18 x 5/16 cup, pt hdls hex soc set

1шт.

9

829393C1

ANGLE

drive shaft shield support

4шт.

113-206

BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, Full Thd

3/8-16 x 3/4 hex-hd

6шт.

180122

BOLT,Hex, 3/8" - 16 x 1", Gr 5

3/8 x 1 type 5

2шт.

120377

NUT,3/8" - 16, Gr 5

8шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

8шт.

10

829396C2

ANGLE

drive shaft shield 12-1/2 ft

1шт.

10

829397C2

ANGLE

drive shaft shield 14-1/2 ft

1шт.

10

829398C2

ANGLE

drive shaft shield 16-1/2 ft

1шт.

10

831295C3

ANGLE

drive shaft shield 19-1/2 ft

1шт.

11

829352C1

SPACER

drive sprocket, for use w/hay conditioner, prior to serial no. 3101

1шт.

12

828807C1

SPROCKET ASSY.

SPROCKET ASSY, hc drive, for use w/hay conditioner, prior to serial no. 3101

1шт.

38904K

SET SCREW,1/2" - 20 x 1-9/16"

SCREW, sprocket retaining set

1шт.

124934

HOSE

1/2-20 hex-jam

1шт.
