Запчасти Case IH 8820 (5-6) - HAY CONDITIONER SPRING ASSEMBLY (09) - CHASSIS

1

7883325

BOLT,Hex, 5/16" - 18 x 3/4", Gr 120M

5/16-18 x 3/4 HWHMS

10шт.

2

704239

FRONT AXLE

5/16-18 HFSLN

12шт.

3

6835896

STRAP

2шт.

4

1310D

LINK

- connector, #50 R/C (With pins)

4шт.

5

1791D

CHAIN (AG),#50, 192 Links x 15.88mm = 3048mm

CHAIN - roller, #50 (10 foot bulk length)

1шт.

6

700108747

SPARE PART

ADAPTER WA

1шт.

7

866418

U-BOLT,U, 5/16" - 18 x 1 .496"

1шт.

8

6835920

BOLT,Hex, 3/4" - 10 x 12.913", Gr 2

WA

1шт.

9

51200166

WASHER

- nylon

1шт.

10

412916

PLUG

- spring

1шт.

11

39917

PLASTIC-RUBBER TUBE

TUBE - neoprene

3шт.

12

287805

PLUG

- spring

1шт.

13

700108742

GUIDE

CHANNEL WA

1шт.

14

428920

BOLT

DRAWBOLT

1шт.

15

704254

NUT,Flg, USR, 1/2"-13

1/2-13 HFSLN

1шт.

16

433045

SPRING

ASSEMBLY (Includes items 10 and 12)

1шт.

17

700108745

SHIELD

1шт.
