Артикул
Название
Примечание
Количество
1
87674849
CUTTERBAR
Complete
1шт.
Does not include PTO Assembly or guards.
1шт.
3
86629689
DISC
2шт.
Modules 2 and 9.
1шт.
5
86515925
FLANGE BOLT,Hex, 1/2" - 13 x 1", Gr 8
20шт.
6
86621872
BLADE
CW, 14°, Standard Equipment
10шт.
Modules 1, 2, 4, 6 and 8.
1шт.
6
86532078
KNIFE
Straight (Also Called "V")
10шт.
6
87029587
BLADE
CW, Over Serrated, 14°
10шт.
6
9847683
BLADE,Knife CW
CW, 7°
10шт.
7
87725066
NUT
20шт.
8
86629691
ARM
LH
1шт.
8
86629690
ARM
RH
1шт.
Not Shown
1шт.
10
0C
ORDER COMPONENTS
Module, CW
5шт.
11
87057898
ARM ASSY.
LH
1шт.
11
87057901
ARM ASSY.
RH
1шт.
Not Shown
1шт.
12
86521614
BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5
4шт.
13
87528245
KIT
Lifter, CW, Includes: (2) Lifters, Hardware & Instructions
10шт.
Modules 1, 2, 4, 6 and 8.
1шт.
14
87047845
STONEGUARD
10шт.
15
86501934
THREADED ROD
20шт.
16
87044107
SPACER
7шт.
17
87056089
PTO SHAFT
LH
1шт.
17
87388046
PTO SHAFT
RH
1шт.
18
86513238
LOCK WASHER,.515” ID x 1.070” OD x .120” TK
32шт.
19
87646406
DISC
10шт.
20
87584169
BOLT,5/8" - 11 x 1-1/2"
Cap, 12 Pt, Flg Hd, 5/8"-11 x 1 1/2", Locking Patch
2шт.
Modules 2 and 9.
1шт.
21
574245
WASHER,16.76mm ID x 50.8mm OD x 6.35mm Thk
10шт.
Included in kit 87642200.
1шт.
22
87580643
REPAIR KIT
Shock Hub, See Figure 20.14.05 [04]
8шт.
23
84141953
SKID/SHOE
HD HT, For Abrasive Soil Conditions
10шт.
23
87622885
SHOE
Skid, High Stub
10шт.
24
86519039
SHAFT
268mm
2шт.
25
87659928
BUSHING,25.4mm ID x 36.5mm OD x 22.23mm L
Spherical
4шт.
26
86621873
BLADE
CCW, 14°, Standard Equipment
10шт.
26
87029588
BLADE
CCW, Over Serrated, 14°
10шт.
26
9847684
BLADE,Knife CCW
CCW, 7°
10шт.
27
86519042
SHAFT
248mm
7шт.
27
9861804DS
GREASE
14oz. Tube
1шт.
28
0C
ORDER COMPONENTS
Module, CCW
5шт.
29
87581143
CAP
See Also: Fig. 20.14.05[04]
8шт.
30
87528249
KIT
Lifter, CCW, Includes: (2) Lifters, Hardware & Instructions
5шт.
Modules 3, 5, 7, 9 and 10.
1шт.
31
271429
SNAP RING,1.625", Int, #162
4шт.
32
86624751
KNIFE SET
Includes (10) Ref. 6, 14° CW Blades, & (10) Ref. 26, 14° CCW Blades
1шт.
32
86624752
KNIFE SET
Includes (16) Ref. 6, 14° CW Blades, & (16) Ref. 26, 14° CCW Blades
1шт.
32
87037027
SET OF BLADES
Includes (16) Ref. 6, 14° CW OS Blades, & (16) Ref. 26, 14° CCW OS Blades
1шт.
33
86512328
WASHER,19.46mm ID x 35.05mm OD x 3.43mm Thk
40шт.
34
86533474
FLANGE BOLT,Hex, 1/2" - 13 x 1", Gr 5
16шт.
35
9790143
BOLT,Hex, 1/2" - 13 x 1", Gr 8, Full Thd
52шт.
36
86544265
FLANGE NUT,Flg, 1/2"-13, G8
20шт.
39
87061791
DRUM
LH, Short
2шт.
39
87390432
DRUM
RH, Long
2шт.
41
86521552
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
8шт.
42
9823743
FLANGE NUT,Flg, 5/16"-18
8шт.
43
88902
NUT,3/8"-16
4шт.
44
280260
BOLT,Hex, 3/8" - 16 x 3", Gr 8
4шт.
46
87609027
CHANNEL
1шт.
47
86589278
BELLEVILLE WASHER,17mm ID x 41.5mm OD x 4.5mm Thk
8шт.
Included in kit 87642200.
1шт.
48
87376405
LOCK WASHER,28.68mm ID x 56mm OD x 6.35mm Thk
8шт.
49
87376403
SEAL
8шт.
Included in kit 87642200.
1шт.
50
87044113
HUB ASSY.
2шт.
Modules 2 and 9.
1шт.
51
86515926
FLANGE BOLT,Hex, 1/2" - 13 x 1.75", Gr 8
20шт.
52
87579665
BOLT,5/8" - 11 x 1-3/4"
Cap, 12 Pt, Flg Hd, 5/8"-11 x 1-3/4", Locking Patch
8шт.
MY2010
1шт.
Included in kit 87642200.
1шт.
Выбрано товаров: 77
