Запчасти Case IH 950 (28) - HEADER U-JOINT AND REVERSE DRIVE, 950 WINDROWER

1

FH267625

SET OF BELTS

SET OF 3 BELTS (Matched), Header drive

1шт.

2

FHO61739

KEY

- gib

2шт.

3

FH264036

FLANGE

2шт.

4

FHO56325

BELT

- wheel drive

2шт.

5

FH132647

GUIDE - belt

3шт.

6

FH156612

KEY

1шт.

7

F51085

BEARING

- (Fafnir #1103KRRB-3)

1шт.

8

O697CB

X

COLLAR

1шт.

9

O650CB

X

FLANGE

2шт.

10

FHO47456

COUPLING - hydraulic pump

1шт.

11

O4284CS

X

KEY

2шт.

12

FH269282

BRACE - hydraulic pump

1шт.

13

FH268219

MOUNTING - hydraulic pump

1шт.

14

FHO85167

COUPLING

- hydraulic pump

1шт.

15

FHO85936

SPIDER ASSY.

SPIDER

1шт.

16

FH267922

BRACKET - support

1шт.

17

FH270728

SHAFT - drive

1шт.

18

FHO56333

BELT

Reverse Drive, VH4D engine

1шт.

18

FHO57083

BELT

Reverse Drive, VG4D Engine

1шт.

19

FH236653

PULLEY - reverse drive

1шт.

20

F2430

PULLEY - vari-steering drive

1шт.

ROLL PIN - 1/4" x 1-3/8" (138-137)

1шт.

21

FH268953

GUIDE - belt

2шт.

22

K3315

BEARING ASSY

BEARING - (Fafnir #RA104NPPB)

1шт.

23

0885CB

COLLAR

1шт.

24

FH267914

SHEAVE - header drive (VG4D engine)

1шт.

24

FH270058

SHEAVE - header drive (VH4D engine)

1шт.
