Артикул
Название
Примечание
Количество
1
758318C1
SNAP RING,#98, Ext
Ring, Snap, , brake drum #98, Ext
2шт.
2
609836R1
WASHER
1-1/32 x 1-3/4 x 16 ga
1шт.
3
595211R1
DRUM, brake (also refer to "BRAKE CONTROL" in section "H" of this parts catalog)
2шт.
4
557995R11
COLLAR
final drive housing shaft inner brg (includes 1 - 115321, SCREW) (for use w/566933R91 or 586649R91, BEARING)
2шт.
115321
SET SCREW,Hex Skt, 5/16"-18 x 5/16"
SCREW, 5/16 x 5/16" hdls-cup-pt-set
2шт.
4
598429R11
COLLAR, final drive housing shaft inner brg (includes 1 - 115321, SCREW) (for use w/598428R91, BEARING)
2шт.
115321
SET SCREW,Hex Skt, 5/16"-18 x 5/16"
SCREW, 5/16 x 5/16" hdls-cup-pt-set
2шт.
5
566933R91
BEARING
housing shaft inner (opt to use 598428R91 or 586649R91, BEARING)
2шт.
5
598428R91
BEARING, housing shaft inner (opt to use 566933R91 or 586649R91, BEARING)
2шт.
5
586649R91
BEARING
housing shaft inner (opt to use 566933R91 or 598428R91, BEARING)
2шт.
6
595223R1
BAR, gear shift lower
2шт.
120378
NUT,Hex, 1/2" - 13, Gr 5
NUT, 1/2"-13, G5
2шт.
120384
WASHER,1/2"
LOCK, 1/2"
2шт.
7
306358R1
O-RING
gear shift lever stud (for use on 275 Windrower built prior to machine serial No. 2867) (for use on 375 Windrower built prior to machine serial No. 982)
2шт.
7
352221R1
O-RING,0.103" Thk x 0.549" ID, -113, Cl 5, 75 Duro
lever stud (for use on 275 Windrower built w/machine serial No. 2867 & since) (for use on 375 Windrower built w/machine serial No. 982 & since)
2шт.
8
595221R11
COVER, housing inner entrance
2шт.
180077
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
5/16 x 3/4"
16шт.
598058R1
SEALING WASHER
LK-WASHER, rubberized
16шт.
9
595036R1
GASKET
entrance cover
2шт.
10
595224R2
STUD, gear shift lever
2шт.
120378
NUT,Hex, 1/2" - 13, Gr 5
NUT, 1/2"-13, G5
2шт.
120384
WASHER,1/2"
LOCK, 1/2"
2шт.
11
595225R1
LEVER, gear shifter
2шт.
19534R1
PIN,1/4" x 1 1/2", Coiled
2шт.
12
21289R1
SNAP RING,#143, Ext
Ring, Snap, , drive sprocket #143, Ext
2шт.
13
595230R1
WASHER, drive sprocket thrust
4шт.
14
595229R11
HUB, housing shaft drive sprocket
2шт.
19996R1
DOWEL,3/8" x 7/8"
PIN, 3/8 x 7/8" roll
4шт.
15
595205R1
RETAINER, final drive housing shaft
2шт.
295204R1
O-RING,0.103" Thk x 2.8" ID, -149, Cl 5, 75 Duro
retainer
2шт.
16
595206R91
GASKET
housing shaft oil
2шт.
17
567847R1
BEARING, CUP,76.22mm OD x 17.46mm W
CUP, housing shaft intermediate brg
2шт.
18
567848R91
CONE
housing shaft intermediate brg
2шт.
19
595204R1
SHAFT
final drive housing
2шт.
20
618023R91
BEARING ASSY,34.93mm ID x 18.2mm W
CONE, housing shaft outer brg
2шт.
21
618024R1
BEARING CUP,65.113mm OD x 13.97mm W
Housing shaft outer
2шт.
22
5125870R1
PLUG, final drive housing frost
2шт.
23
595216R1
HOUSING, final drive (for component parts of this assembly refer to "FINAL DRIVE" and "FINAL DRIVE AXLE" in section "B" of this parts catalog)
2шт.
24
595227R1
SPROCKET ASSY.
SPROCKET, 66T final drive housing shaft drive (for use on 275 Windrower)
2шт.
24
595228R1
SPROCKET, 37T final drive housing shaft drive (for use on 375 Windrower)
2шт.
19042R1
BOLT,7/16"-14 x 1 1/2", G2, Full Thd
7/16 x 1-1/2" No. 3 plow
12шт.
271501
SOCKET
NUT, 7/16"
12шт.
120383
LOCK WASHER,Helical Spring, 7/16"
WASHER, LOCK, 7/16"
12шт.
25
595226R1
COUPLING, gear shift lever
2шт.
26
17011R1
BALL
11/32" shift lever coupling
2шт.
27
606245R1
SPRING
shift lever coupling
2шт.
28
327086R1
SNAP RING
O-RING, housing shaft inner brg
2шт.
29
595209R1
GASKET
brg retaining
2шт.
30
21288R1
RING,#244, 2.546, Int, Spiral
housing shaft inner brg retaining
2шт.
31
595208R1
RETAINER, housing shaft inner brg
2шт.
180124
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5
3/8 x 1-1/4"
8шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
8шт.
32
595210R1
GUARD, brake band reinforcement
2шт.
180124
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5
3/8 x 1-1/4"
4шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
4шт.
Выбрано товаров: 55
