Запчасти Case IH 230 (16-13) - PLATFORM, KNIFE DRIVE AND SUPPORTS Platform

1

825661C1

PITMAN

knife drive

1шт.

2

425-1516

JAM NUT,Jam, 1"-14, G5

1" jam

1шт.

3

823453C91

JOINT

ASSY, bellcrank ball composed of: (1) joint (NSS), (1) nut, (1) seal 151926C1

1шт.

102903H1

NUT

5/8", NF SLT

1шт.

103386

COTTER PIN,1/8" x 1 1/4"

Pin, Split (Cotter), 1/8" x 1 1/4"

1шт.

109461

LUBE NIPPLE,1/8"-27 x .66 lg

NIPPLE, LUBE, 1/8"-27 x .66 lg

1шт.

464623R1

WASHER

21/32 x 1-1/2 x 11 ga (as req'd)

2шт.

4

151926C1

SEAL

SEAL, bellcrank ball joint

1шт.

5

824969C1

SUPPORT

bellcrank

1шт.

180173

BOLT,Hex, 1/2" - 13 x 1", Gr 5

1шт.

180175

BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5

1/2 x 1-1/4"

2шт.

180177

BOLT,Hex, 1/2" - 13 x 1 1/2", Gr 5

1/2 x 1-1/2"

2шт.

20601R1

WASHER

17/32 x 1-1/4 x 11 ga

7шт.

120378

NUT,Hex, 1/2" - 13, Gr 5

NUT, 1/2"-13, G5

5шт.

120384

WASHER,1/2"

LOCK, 1/2"

5шт.

6

20575R1

BOLT,Hex, 3/4" - 10 x 8", Gr 5

3/8 x 8" bellcrank pivot

1шт.

280954

NUT,3/4"-10, G5

2шт.

7

825605C1

WASHER

knife bellcrank

2шт.

8

564808R91

WIPER

SEAL, bellcrank pivot oil

2шт.

9

142929H

NEEDLE BEARING,Needle, 28.56mm ID x 34.94mm OD x 25.4mm W

BEARING, bellcrank pivot

2шт.

10

823410C1

BUSHING

bellcrank pivot

1шт.

11

823414C2

PIVOT

knife drive bellcrank

1шт.

109461

LUBE NIPPLE,1/8"-27 x .66 lg

NIPPLE, LUBE, 1/8"-27 x .66 lg

1шт.

12

825699C1

BLOCK

knife drive ball joint

1шт.

13

826287C1

BOLT,5/8" - 18 x 3", Gr 5

5/8" wheel type

2шт.

14

824812C91

END

knife head (for service parts refer to "Knife and Guards")

1шт.

15

825338C1

WASHER

bellcrank pivot (as req'd)

6шт.

15

825389C1

WASHER

bellcrank pivot (as req'd)

2шт.

16

595741R1

WASHER

bellcrank

1шт.
