Артикул
Название
Примечание
Количество
1
938885R1
GRIP
variable speed control lever
1шт.
2
LEVER, w/ROCKSHAFT, variable speed control (For service order 1-825345C1 ROCKSHAFT and 1-599038R3 LEVER)
1шт.
3
599038R3
LEVER, variable speed control
1шт.
4
599040R1
SECTOR, variator control
1шт.
495967R1
CARRIAGE BOLT,Short NK, 3/8"-16 x 1", G5, Full Thd
BOLT, 3/8 x 1" crg
3шт.
120377
NUT,3/8" - 16, Gr 5
3шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
3шт.
5
599039R1
STUD, lever
1шт.
271501
SOCKET
NUT, 7/16"
1шт.
120383
LOCK WASHER,Helical Spring, 7/16"
WASHER, LOCK, 7/16"
1шт.
6
ROCKSHAFT W/LEVER, variable control (For service order 1-825345C1 ROCKSHAFT and 1-599038R3 LEVER)
1шт.
180122
BOLT,Hex, 3/8" - 16 x 1", Gr 5
3/8 x 1"
2шт.
609836R1
WASHER
1-1/32 x 1-3/4 x 16 ga
1шт.
120377
NUT,3/8" - 16, Gr 5
2шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
2шт.
432-1624
COTTER PIN,1/4" x 1 1/2"
Pin, Split (Cotter), 1/4" x 1 1/2"
1шт.
7
825345C1
ROCKSHAFT, variator control
1шт.
180124
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5
3/8 x 1-1/4"
2шт.
609836R1
WASHER
11/32 x 1-3/4 x 16 ga
1шт.
120377
NUT,3/8" - 16, Gr 5
2шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
2шт.
8
826215C1
SUPPORT, brace
1шт.
180173
BOLT,Hex, 1/2" - 13 x 1", Gr 5
2шт.
178374R1
WASHER
17/32 x 1-1/4 x 16 ga
2шт.
120378
NUT,Hex, 1/2" - 13, Gr 5
NUT, 1/2"-13, G5
2шт.
120384
WASHER,1/2"
LOCK, 1/2"
2шт.
9
823023C1
BAR, variator frame outer support LH
1шт.
180177
BOLT,Hex, 1/2" - 13 x 1 1/2", Gr 5
1/2 x 1-1/2"
2шт.
120378
NUT,Hex, 1/2" - 13, Gr 5
NUT, 1/2"-13, G5
2шт.
120384
WASHER,1/2"
LOCK, 1/2"
2шт.
10
824941C1
FRAME, variator outer
1шт.
495967R1
CARRIAGE BOLT,Short NK, 3/8"-16 x 1", G5, Full Thd
BOLT, 3/8 x 1" crg
4шт.
20803R1
WASHER
13/32 x 1 x 11 ga
4шт.
120377
NUT,3/8" - 16, Gr 5
4шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
4шт.
11
826174C1
BAR, variator frame support RH
1шт.
180179
BOLT,Hex, 1/2" - 13 x 1 3/4", Gr 5
1/2 x 1-3/4"
3шт.
120378
NUT,Hex, 1/2" - 13, Gr 5
NUT, 1/2"-13, G5
3шт.
120384
WASHER,1/2"
LOCK, 1/2"
3шт.
12
825749C1
FRAME, variator inner
1шт.
180077
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
5/16 x 3/4"
6шт.
80681
LOCK WASHER,5/16"
WASHER, LOCK, 5/16"
6шт.
13
599044R1
BOLT, variator control adjusting
1шт.
21796R1
WASHER
21/32 x 1 x 16 ga
1шт.
120371
NUT,1/2"-20, G5
1шт.
14
104039
ADJUSTABLE CLEVIS,1/2"-20 x 3"
YOKE, 1/2" rod end
1шт.
103498
CLEVIS PIN,1/2" x 1.360"
PIN, 1/2 x 1-27/64" rod end
1шт.
103384
COTTER PIN,1/8" x 3/4"
Pin, Split (Cotter), 1/8" x 3/4"
1шт.
15
599041R1
SUPPORT, variator shaft
1шт.
495967R1
CARRIAGE BOLT,Short NK, 3/8"-16 x 1", G5, Full Thd
BOLT, 3/8 x 1"
2шт.
120377
NUT,3/8" - 16, Gr 5
2шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
2шт.
16
599046R2
ROCKSHAFT, variator control LH
1шт.
180124
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5
3/8 x 1-1/4"
2шт.
609836R1
WASHER
1-1/32 x 1-3/4 x 16 ga
1шт.
120377
NUT,3/8" - 16, Gr 5
2шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
2шт.
17
599071R2
SHIELD
variator belt
1шт.
180077
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
5/16 x 3/4"
4шт.
80681
LOCK WASHER,5/16"
WASHER, LOCK, 5/16"
4шт.
18
825685C1
BOLT, variator adjuster
1шт.
120238
JAM NUT,Jam, 1/2"-13, G5
1/2" jam
4шт.
19
826159C2
SUPPORT
variator lever bearing
2шт.
9635884
BOLT,Hex, 5/16" - 18 1", Full Thd, Gr 5
5/16 x 1"
4шт.
120376
NUT,5/16"-18, G5
4шт.
80681
LOCK WASHER,5/16"
WASHER, LOCK, 5/16"
4шт.
20
461049R1
OIL SEAL
RING, rockshaft spacer LH
1шт.
Выбрано товаров: 68
