Запчасти Case IH 210 (A-07) - CHASSIS, RADIATOR AND SHEET METAL, PLATFORM LIFT AND FLOAT Chassis, Radiator & Sheet Metal

1

355681R1

SPACER, hyd cylinder front pin (Prior to Serial No. 3700)

4шт.

2

591990R1

PIN, hydraulic cylinder front

2шт.

432-1624

COTTER PIN,1/4" x 1 1/2"

Pin, Split (Cotter), 1/4" x 1 1/2"

4шт.

3

591989R91

CYLINDER ASSY, platform lift hyd (For service parts refer to "PLATFORM LIFT HYDRAULIC CYLINDER" Section F)

2шт.

4

592186R1

SPACER, lift cylinder rear anchor

2шт.

413-1256

BOLT,Hex, 3/4" - 10 x 3-1/2", Gr 5

3/4 x 2-1/2"

2шт.

280954

NUT,3/4"-10, G5

2шт.

5

594398R93

BRACKET ASSY, float spring (LH Shown) (Includes 2-592180R1, BUSHING)

1шт.

5

594399R93

BRACKET ASSY, float spring (RH) (Includes 2-592180R1 BUSHING)

1шт.

271294

WASHER

5/16-NF 65 lub

2шт.

6

592180R1

BUSHING, float spring bracket

4шт.

7

592181R1

SPACER, float spring clevis

4шт.

8

455369R2

CLEVIS

platform float spring

2шт.

180132

BOLT,Hex, 3/8" - 16 x 2 1/4", Gr 5

3/8 x 2-1/4"

2шт.

619856R1

WASHER

13/32 x 1 x 16 ga

4шт.

120377

NUT,3/8" - 16, Gr 5

2шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

2шт.

9

594390R1

SPRING, platform float

2шт.

10

594391R1

PLUG, float spring

2шт.

11

592184R2

BOLT, float spring

2шт.

20601R1

WASHER

17/32 x 1-1/4 x 11 ga

2шт.

120238

JAM NUT,Jam, 1/2"-13, G5

3/8" jam

2шт.

12

591991R12

PIVOT, platform lift cylinder rear

2шт.

180121

BOLT,Hex, 3/8" - 16 x 7/8", Gr 5

3/8 x 7/8"

2шт.

120377

NUT,3/8" - 16, Gr 5

2шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

2шт.
