Запчасти Case IH 201 (A-038) - RADIATOR AND SUPPORTS, CARBURETED (10) - ENGINE
№
Артикул
Название
Примечание
Количество
1
613342R91
RADIATOR (includes 361705R91, cap) (opt w/613311R91, radiator)
1шт.
18526R1
LOCK NUT,7/16"-14, GB
NUT, 7/16" stop
2шт.
Q303
WASH, 17/32 sq-holex 1-1/2 x 11 ga
2шт.
76730H
WASHER
WASH, 17/32 x 1-1/2 x 11 ga
2шт.
LK-WASH, 7/16"
2шт.
1
613311R91
RADIATOR (includes 361705R91, cap & 444578 or 112578, plug) (opt w/613342R91, radiator)
1шт.
18526R1
LOCK NUT,7/16"-14, GB
NUT, 7/16" stop
2шт.
Q303
WASH, 17/32 sq-hole x 1-1/2 x 11 ga
2шт.
76730H
WASHER
WASH, 17/32 x 1-1/2 x 11 ga
2шт.
BOLT, 7/16 x 2-1/4" crg
2шт.
LK-WASH, 7/16"
2шт.
2
361705R91
COVER
CAP, radiator
1шт.
3
610286R1
BRACE, radiator
1шт.
BOLT W/NUT, 5/16 x 7/8" mach
2шт.
BOLT, 3/8 x 3/4" type 2
1шт.
BOLT, 3/8 x 1" type 2
2шт.
Q1597
WASHER
WASH, 13/32 x 3/4 x 16 ga
2шт.
LK-WASH, 5/16"
2шт.
LK-WASH, 3/8"
3шт.
4
39170H
CLAMP
inlet hose upr
1шт.
5
369094R1
RADIATOR HOSE,1.76" ID, 2.50" ID x 5.40"
Radiator Inlet 1.76" ID, 2.50" ID x 5.40"
1шт.
6
39240H
CLAMP
inlet hose lower
1шт.
7
278555R1
HOSE, outlet upper
1шт.
8
39142H
COLLAR CLAMP
CLAMP, outlet hose upr
2шт.
9
612712R1
HOUSING, radiator fan
1шт.
BOLT, 1/4-NF x 3/8" type 2 (w/613342R91, radiator)
2шт.
BOLT, 1/4-NF x 5/8" type 2
2шт.
BOLT W/NUT, 1/4 x 4-3/4" type 2 (w/613311R91, radiator)
2шт.
LK-WASH, 1/4"
4шт.
10
119093
ELBOW, 3/8"-45deg. (613342R91, radiator)
1шт.
11
13047DA
PLUG
CAP, drain (w/613342R91, radiator)
1шт.
11
143162
PLUG
3/8" (w/613311R91, radiator)
1шт.
12
221-1166
NIPPLE, LUBE
NIPPLE, 3/8 x 3" (613342R91, radiator)
1шт.
13
368602R1
ELBOW, radiator outlet
1шт.
14
55624D
CLAMP
outlet hose lower
2шт.
15
611404R1
HOSE, radiator outlet
1шт.
16
612326R92
SUPPORT, radiator
1шт.
BOLT W/NUT, 1/2 x 1-1/8" mach
3шт.
BOLT, 5/8 x 1-3/4" mach
1шт.
BOLT W/NUT, 5/8 x 2" mach
2шт.
BOLT W/NUT, 5/8 x 2-1/2" mach
1шт.
LK-WASH, 1/2"
3шт.
LK-WASH, 5/8"
4шт.
17
271928R1
GROMMET
MOUNT, radiator bolt rubber
2шт.
Выбрано товаров: 44
