Запчасти Case IH 201 (E-048[1]) - REEL SUPPORT ARM (58) - ATTACHMENTS/HEADERS

1

611761R1

BRACKET, reel tube brg

2шт.

109461

LUBE NIPPLE,1/8"-27 x .66 lg

NIPPLE, LUBE, 1/8"-27 x .66 lg

2шт.

517843R1

COTTER PIN

C-PIN, quick-attachable

2шт.

LC175

PIN

1/2 x 2-1/2" std-hd dld

2шт.

2

591724R92

ARM, reel support (LH)

1шт.

2

607636R31

ARM, reel support (RH)

1шт.

614451R1

WASHER

C-Z WASHER, 1-1/32 x 1-3/4 x 11 ga (LH)

1шт.

3

607637R2

BRACE, reel support arm

2шт.

113-206

BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, Full Thd

3/8 x 3/4" C-Z type 2

2шт.

495967R1

CARRIAGE BOLT,Short NK, 3/8"-16 x 1", G5, Full Thd

BOLT W/NUT, 3/8 x 1" C-Z type 2 crg

2шт.

180122

BOLT,Hex, 3/8" - 16 x 1", Gr 5

3/8 x 1" C-Z type 2

2шт.

20803R1

WASHER

13/32 x 1 x 11 ga C-Z

2шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

6шт.

4

610513R1

COLLAR

COLLAR, support arm locking

2шт.

NLS

NO LONGER SERVICED

SCREW, 5/16 x 1/2" sq-hd cup-pt C-Z set

2шт.
