Запчасти Case IH 201 (A-015[A]) - INSTRUMENT PANEL (10) - ENGINE

1

612312R1

PANEL, instrument

1шт.

BOLT W/NUT, 5/16 x 5/8" mach

2шт.

BOLT, 1/2 x 3/4" type 2

1шт.

Q398

WASHER

11/32 x 7/8 x 16 ga

1шт.

LK-WASHER, 5/16"

2шт.

LK-WASHER, 1/2"

1шт.

2

62801DC

SWITCH

light

1шт.

3

362039R94

GAUGE

oil pressure (opt w/393488R91)

1шт.

3

393488R91

SWITCH

GAUGE, oil pressure (opt w/362039R94)

1шт.

4

612317R91

CABLE, choke (w/knob)

1шт.

5

INDICATOR, heat (for component parts refer to "heat indicator")

1шт.

6

360053R92

INDICATOR

AMMETER, battery

1шт.

7

366317R91

IGNITION SWITCH

BUTTON, engine starting

1шт.

SCREW, no. 10 x 7/16" cd-pltd slt-rd-hd

2шт.

NUT, no. 10 cd-pltd

2шт.

LK-WASHER, no. 10 cd-pltd

2шт.

8

62801DC

SWITCH

ignition

1шт.

21053R1

WASHER

19/32 x 1-1/4 x 11 ga cd-pltd

1шт.
