Запчасти Case IH 201 (E-044[1]) - PICK-UP REEL BAT, 13-1/2 FT (58) - ATTACHMENTS/HEADERS

1

598171R1

TINE,Coiled, 1 Prong, 283mm L

reel bat

160шт.

2

592616R1

CLIP

reel bat tine

160шт.

20901R1

RIVET

3/16 x 1" semi-tub ov-hd

160шт.

3

BAT, inner-clip, tine & wood (order 1-598207R91) (NSS)

5шт.

4

598206R1

BATSHAFT, reel bat

5шт.

18629R1

SCREW,Short NK, 1/4"-20 x 1 1/2", G2

BOLT, 1/4 x 1-1/2" C-Z crg

110шт.

378531R1

LOCK NUT,1/4"-20, GA

LK-NUT, 1/4" special

110шт.

5

598207R91

BAT ASSEMBLY, inner composed of: (1) bat (NSS), (10) clip 592616R1, (10) tine 598171R1, (10) rivet 20901R1

5шт.

6

BAT, outer-clip tine & wood (order 1-598189R91 bat assembly) (NSS)

10шт.

7

598189R91

BAT

ASSEMBLY, outer composed of: (1) bat (NSS), (11) clip 592616R1, (11) tine 598171R1, (11) rivet 20901R1

10шт.

8

598205R91

BATSHAFT & BAT ASSEMBLY, composed of: (1) bat assembly 598207R91, (2) bat assembly 598189R91, (1) shaft 598206R1

5шт.
