Запчасти Case IH 201 (D-027) - REEL DRIVE (58) - ATTACHMENTS/HEADERS

1

ARM, reel support LH (refer to "reel support arm, LH")

1шт.

2

609917R1

SUPPORT, idler tightener (1965 & since)

1шт.

3

609778R1

BOLT, tightener support (1965 & since)

1шт.

NUT, 3/8" cd-pltd

2шт.

4

614451R1

WASHER

1-1/32 x 1-3/4 x 11 ga cd-pltd

1шт.

5

617363R1

BUSHING

reel drive hub

1шт.

6

554575R91

PULLEY, reel drive

1шт.

BOLT, 3/8 x 1" mach

3шт.

LK-WASH, 3/8"

3шт.

7

607666R1

V-BELT,0.63" W

Reel & countershaft drive 0.63" W

1шт.

8

CRANKSHAFT, pitman (refer to "pitman crankshaft & drive")

1шт.

9

592730R1

PULLEY

reel drive half

2шт.

BOLT, 5/16 x 1-1/8" mach

4шт.

LK-WASH, 5/16"

4шт.

10

610513R1

COLLAR

COLLAR, support arm locking

1шт.

142671

SET SCREW

SCREW, 5/16 x 1/2" sq-hd cup-pt cd-pltd set

1шт.

11

21659K

RING

SPACER, pulley half

5шт.

12

611754R21

HUB, drive pulley (includes 617363R1, bush)

1шт.

13

554653R2

V-BELT,0.63" W

Reel drive (prior to 1965) 0.63" W

1шт.

13

18884K

V-BELT,147.21" L

Reel drive (1965 & since) 147.21" L

1шт.

14

304616R1

SPACER, idler pulley (1965 & since)

2шт.

15

611755R1

HUB

reel driven pulley

1шт.

617978R1

PIN,3/8" x 2 1/2", Coiled

1шт.

16

559087R92

PULLEY

belt idler upper

1шт.

BOLT W/NUT, 1/2 x 2-1/2" cd-pltd mach

1шт.

LK-WASH, 1/2" cd-pltd

1шт.

17

559292R92

NO LONGER SERVICED

PULLEY, belt idler lower

1шт.

BOLT W/NUT, 1/2 x 2-1/2" cd-pltd mach

1шт.

LK-WASH, 1/2" cd-pltd

1шт.

18

588227R11

PULLEY

reel driven

1шт.

BOLT W/NUT, 3/8 x 1-1/2" mach

3шт.

LK-WASH, 3/8"

3шт.

19

610514R1

HANDLE, idler adjustment, Serial Range: (prior-1965)

1шт.

20

607675R1

BRACKET, idler support, Serial Range: (prior-1965)

1шт.

BOLT W/NUT, 3/8 x 7/8" crg

2шт.

LK-WASH, 3/8"

2шт.

21

610518R11

BRACKET, idler mounting, Serial Range: (prior-1965)

1шт.

NUT, 1/2"

2шт.

LK-WASH, 1/2"

2шт.
