Запчасти Case IH 201 (D-013[A]) - UNIVERSAL JOINT, 1000 RPM, HAYES STEEL (58) - ATTACHMENTS/HEADERS

1

613867R11

PIN

yoke release (includes 17078R1, pin & 613868R1, spg)

1шт.

613868R1

SPRING

SPG, release pin

1шт.

17078R1

LOCK PIN,1/8" x 13/16", Slotted

PIN, 1/8" x 13/16", Slotted

1шт.

2

609153R11

BEARING

center cross needle

8шт.

3

609154R1

RING

brg snap outer

8шт.

4

609143R91

SIHELD, yoke & shaft outer

1шт.

5

609147R91

SHIELD, yoke & tube inner

1шт.

6

607911R1

NYLON BEARING,1.781" ID x 0.25"

BEARING, nylon

1шт.

7

609148R1

YOKE

rear splined

1шт.

20151R1

SCREW

yoke set

1шт.

114496

HOURMETER,Jam, 1/2"-20, G5

NUT, screw jam

1шт.

8

609144R91

CROSS

ASSEMBLY, universal center composed of: (4) bearing 609153R11, (1) cross (NSS), (1) fitting 109460, (4) ring 609154R1

2шт.

9

609146R91

YOKE & TUBE, universal rear

1шт.

10

609142R91

YOKE & SHAFT, universal front

1шт.

11

607910R1

BEARING HALF

nylon half

4шт.

12

CROSS, center (order 1-609144R91, cross) (NSS)

2шт.

80711

LUBE NIPPLE,65 Degree, 1/8" NPT x 7/8" lg

LUB-FTG, 1/8"-65 deg. elbow

2шт.

13

609145R91

YOKE, quick-detachable front (includes 613867R11, pin)

1шт.
