Запчасти Case IH 201 (A-110[A]) - REEL BELT DRIVE, AUGER PLATFORM, NOT CANVAS OR PEA BAR PLATFORM (58) - ATTACHMENTS/HEADERS

1

ARM, reel support RH (refer to "reel support arm RH")

1шт.

2

568237R11

PULLEY, reel driver

1шт.

BOLT, 5/16 x 1" mach

4шт.

LK-WASHER, 5/16"

4шт.

3

609779R2

HUB, reel driver pulley

1шт.

617978R1

PIN,3/8" x 2 1/2", Coiled

1шт.

4

560431R1

V-BELT

Reel drive

1шт.

5

574097R91

PULLEY

idler upr (opt w/936923R91)

1шт.

5

936923R91

PULLEY

idler upr (opt w/574097R91)

1шт.

575098R1

SPACER,16.7mm ID x 22.23mm OD x 15.9mm L

idler pulley

1шт.

BOLT W/NUT, 5/8 x 1-1/2" mach

1шт.

LK-WASHER, 5/8"

1шт.

6

564745R91

PULLEY

idler lower (opt w/610407R91)

1шт.

6

610407R91

BEARING

PULLEY, idler lower ( opt w/564745R91)

1шт.

575098R1

SPACER,16.7mm ID x 22.23mm OD x 15.9mm L

idler pulley

1шт.

BOLT W/NUT, 5/8 x 2-1/2" mach

1шт.

LK-WASHER, 5/8"

1шт.

7

609775R1

BUSHING

reel drive gear

2шт.

8

609774R11

GEAR, reel drive (includes 609775R1, bushings)

1шт.

BOLT W/NUT, 3/8 x 1-3/8" crg

4шт.

LK-WASHER, 3/8"

4шт.

9

609776R1

RETAINER, pulley spacer

5шт.

10

609727R1

PULLEY

reel drive half-pulley

1шт.

BOLT W/NUT, 3/8 x 1-3/8" crg

4шт.

LK-WASHER, 3/8"

4шт.

11

610513R1

COLLAR

COLLAR, reel support arm locking

1шт.

142671

SET SCREW

SCREW, 5/16 x 1/2" cd-pltd sq-hd cup-pt set

1шт.
