Запчасти Case IH 201 (E-012) - ELECTRICAL SYSTEM, BATTERY TRAY, WISCONSIN VH4D ENGINE (55) - ELECTRICAL SYSTEMS

1

592014R92

COVER, battery tray

1шт.

2

PO22778

SPACER,1/4" Pipe x 2"

Hold-down bolt 1/4" Pipe x 2"

2шт.

3

614131R1

BOLT, cover hold-down

2шт.

120392

WASHER,1/4", SAE

9/32 x 5/8 x .065 ga C-Z

2шт.

126177

WING NUT

NUT, 1/4" C-Z wing

2шт.

492-11025

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

2шт.

4

592017R1

ANGLE, battery tray anchor

2шт.

16897R1

CARRIAGE BOLT,Short Nk, 5/16" - 18 x 3/4", Gr 2, Full Thd

BOLT W/NUT, 5/16 x 3/4" C-Z crg

2шт.

80681

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

2шт.

5

592013R1

TRAY, battery

1шт.

113-206

BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, Full Thd

W/NUT, 3/8 x 3/4" C-Z type 2

4шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

4шт.
