Запчасти Case IH 201 (A-057) - COMBINATION WORK AND TAIL LIGHT (55) - ELECTRICAL SYSTEMS

373305R91

LIGHT

6 volt work (dietz & guide lamp) (includes parts listed unless noted)

1шт.

NUT, 1/2"

1шт.

Not part of work light

1шт.

LK-WASH, 1/2"

1шт.

Not part of work light

1шт.

373306R91

LIGHT

12 volt work (dietz & guide lamp) (includes parts listed, unless noted)

1шт.

NUT, 1/2"

1шт.

Not part of work light

1шт.

LK-WASH, 1/2"

1шт.

Not part of work light

1шт.

1

371450R91

BEZEL

MOULDING, beam (dietz)

1шт.

SCREW, no. 8 x 1-1/4" slt-fil-hd

1шт.

LK-WASH, no. 8

1шт.

1

371451R91

MOLDING

MOULDING, beam (guide lamp)

1шт.

53526D

SCREW

moulding

1шт.

2

371458R91

SEALED BEAM UNIT

SEALED BEAM, 6 volt

1шт.

2

371461R91

LENS

SEALED BEAM, 12 volt

1шт.

3

373309R1

KNOB

light switch (dietz)

1шт.

3

359773R1

KNOB, light switch (guide lamp)

1шт.

4

355425R1

NUT, switch tightener (dietz)

1шт.

5

373308R91

LIGHT SWITCH

SWITCH, light (dietz) (includes 373309R1, knob, & 355425R1, nut)

1шт.

5

375653R91

SWITCH

light (guide lamp) (includes 359773R91, knob)

1шт.

6

373311R91

CABLE, switch to terminal (dietz)

1шт.

6

375655R91

CABLE, switch to terminal (guide lamp)

1шт.

7

365664R91

ELEC CONNECTOR

CLIP, block & spg (dietz)

1шт.

7

68417D

INSULATOR

PACKAGE, terminal plate service (guide lamp) (includes 79407H, plate; 121749, screws; 79408H, spg & 138530, washers)

1шт.

8

BODY (order 1-373305R91 - 6 volt or 1-373306R91 - 12 volt light) (NSS)

1шт.

9

49069D

SPACER

tail light stud

1шт.

Not part of work light

1шт.

10

350920R1

CLAMP

tail light

1шт.

Not part of work light

1шт.

11

514986R1

PIVOT, tail light support

1шт.

Not part of work light

1шт.

BOLT W/NUT, 1/2 x 6-3/4" mach

1шт.

Not part of work light

1шт.

LK-WASH, 1/2"

1шт.

Not part of work light

1шт.

11002VA

WASHER

WASH, 17/32 x 7/8 x 16 ga

1шт.

Not part of work light

1шт.

PO10535

WASHER

WASH, 17/32 x 1-1/4 x 11 ga

1шт.

Not part of work light

1шт.

12

454493

BULB, 6 volt work light #209, Type C-6, 6V

1шт.

12

455490

BULB,C-6, #1003, 12V, .94W

12 volt work light

1шт.

13

373310R91

CABLE, switch to socket (dietz)

1шт.

13

375654R91

CABLE, switch to socket (guide lamp)

1шт.

14

373311R91

CABLE, switch to beam (dietz)

1шт.

14

375656R91

CABLE, switch to beam (guide lamp)

1шт.
