Запчасти Case IH 201 (E-032) - CONTROLS AND DRIVES, STEERING (41) - STEERING

1

104038

ADJUSTABLE CLEVIS,3/8"-24 x 2 1/2"

CLEVIS, rockshaft connecting

2шт.

SE235

HEADED PIN,3/8" x 1 1/8"

PIN, 3/8 x 1-1/8" std-hd-dld

2шт.

103373

COTTER PIN,3/32" x 3/4"

Pin, Split (Cotter), 3/32" x 3/4"

2шт.

2

591928R1

ROD

steering link

2шт.

120369

NUT,3/8"-24, G5

1/8"-NF

2шт.

103384

COTTER PIN,1/8" x 3/4"

Pin, Split (Cotter), 1/8" x 3/4"

2шт.

3

591921R1

SPACER, support rod outer

2шт.

4

591924R91

ROCKSHAFT, lever pivot RH

1шт.

271293

PULLEY

LUB-FITTING, 3/16"-NF

1шт.

180147

SCREW,Hex, 7/16" - 14 x 1 1/4", Gr 5

BOLT W/NUT, 7/16 x 1-1/4" C-Z type 2

2шт.

120383

LOCK WASHER,Helical Spring, 7/16"

WASHER, LOCK, 7/16"

2шт.

5

591916R1

GRIP, steering lever

2шт.

6

591918R1

LEVER, steering RH

1шт.

180147

SCREW,Hex, 7/16" - 14 x 1 1/4", Gr 5

BOLT W/NUT, 7/16 x 1-1/4" C-Z type 2

2шт.

120383

LOCK WASHER,Helical Spring, 7/16"

WASHER, LOCK, 7/16"

2шт.

7

591930R91

ROCKSHAFT, clutch throw-out brg RH

1шт.

20703R1

WASHER

29/32 x 1-3/4 x 16 ga C-Z

1шт.

103409

PIN, SPLIT (COTTER),3/16" x 1 1/2"

2шт.

8

591936R1

BAR, clutch throw out support

1шт.

180124

BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5

W/NUT, 3/8 x 1-1/4" C-Z type 2

4шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

4шт.

592806R1

SHIM, support bar

1шт.

9

591929R91

ROCKSHAFT, clutch throw-out brg LH

1шт.

20703R1

WASHER

29/32 x 1-3/4 x 16 ga C-Z

1шт.

103409

PIN, SPLIT (COTTER),3/16" x 1 1/2"

2шт.

10

591917R1

LEVER, steering LH

1шт.

180147

SCREW,Hex, 7/16" - 14 x 1 1/4", Gr 5

BOLT W/NUT, 7/16 x 1-1/4" C-Z type 2

2шт.

120383

LOCK WASHER,Helical Spring, 7/16"

WASHER, LOCK, 7/16"

1шт.

11

591923R91

ROCKSHAFT, lever pivot LH

1шт.

271293

PULLEY

LUB-FITTING, 5/16"-NF

2шт.

180147

SCREW,Hex, 7/16" - 14 x 1 1/4", Gr 5

BOLT W/NUT, 7/16 x 1-1/4" C-Z type 2

2шт.

120383

LOCK WASHER,Helical Spring, 7/16"

WASHER, LOCK, 7/16"

2шт.

12

13985V

SPRING

brg rockshaft return

1шт.

103409

PIN, SPLIT (COTTER),3/16" x 1 1/2"

2шт.

13

591922R1

STRIP, support rod lock

1шт.

413-412

BOLT,Hex, 1/4" - 20 x 3/4", Gr 5

W/NUT, 1/4 x 3/4" C-Z type 2

2шт.

492-11025

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

2шт.

14

591919R1

ROD, rockshaft support

1шт.

15

610732R1

STOP, steering lever

1шт.

113-206

BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, Full Thd

W/NUT, 3/8 x 3/4" C-Z type 2

2шт.

619856R1

WASHER

13/32 x 1 x 16 ga C-Z

2шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

2шт.

16

591920R1

SPACER, rockshaft lever pivot

1шт.
