Запчасти Case IH 201 (D-039[A]) - HYDRAULIC LINES, PLATFORM LIFT (35) - HYDRAULIC SYSTEMS

1

611702R1

END, hyd cyl rod

1шт.

For machines equipped with self-contained hydraulics. One (1) cylinder used on 12 ft platform, two (2) used on 16 ft platform

1шт.

109461

LUBE NIPPLE,1/8"-27 x .66 lg

NIPPLE, LUBE, 1/8"-27 x .66 lg

1шт.

2

607736R1

PIN, front retaining

1шт.

For machines equipped with self-contained hydraulics. One (1) cylinder used on 12 ft platform, two (2) used on 16 ft platform

1шт.

CD-PIN, 1/4 x 1-1/2"

2шт.

3

611726R1

PIN, cyl rod

1шт.

For machines equipped with self-contained hydraulics. One (1) cylinder used on 12 ft platform, two (2) used on 16 ft platform

1шт.

4

CYLINDER, platform lift hyd (for component parts refer to "platform lift hydraulic cylinder")

1шт.

For machines equipped with self-contained hydraulics. One (1) cylinder used on 12 ft platform, two (2) used on 16 ft platform

1шт.

584492R1

PIN

1 x 3" std-hd dld

1шт.

C-PIN, 1/4 x 1-1/2"

1шт.

5

364839R1

O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro

6-1, 90 Duro, .468" ID x .078" Thk, hyd cylinder hose

1шт.

For machines equipped with self-contained hydraulics. One (1) cylinder used on 12 ft platform, two (2) used on 16 ft platform

1шт.

6

607737R91

HOSE, hyd cyl

1шт.

For machines equipped with self-contained hydraulics. One (1) cylinder used on 12 ft platform, two (2) used on 16 ft platform

1шт.

7

9402942

ELBOW,90 Degree, 9/16"-18, 37 Degree x 9/16"-18, 37 Degree

90deg. hyd cyl RH

1шт.

8

607738R11

PIPE, hyd cyl RH (16 ft only)

1шт.

9

76355

TEE,9/16" - 18 JIC x 9/16" - 18 JIC x 9/16" - 18 JIC

hyd cyl pipe (16 ft only)

1шт.

10

607739R11

PIPE, hyd cyl LH

1шт.

11

607740R1

ELBOW, valve reducer bush

1шт.

12

119931

control valve reducer

1шт.
