Запчасти Case IH 201 (E-028) - CONTROLS AND DRIVES, FINAL DRIVE (25) - FRONT AXLE SYSTEM

1

658006R11

COLLAR

W/SCREW, brg locking (Fafnir, SKF & New Departure - use w/564991R91 bearing)

4шт.

1

592247R11

COLLAR

W/SCREW, brg locking (Fisher - use w/592246R91 bearing)

4шт.

83-1254

SET SCREW,Hex Soc, 1/4"-20 x 1/4"

SCREW, 1/4 x 1/4" hdls cup-pt set

4шт.

2

462360R1

FLANGED BEARING

RETAINER, center bearing

4шт.

180077

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

5/16 x 3/4" C-Z type 2

6шт.

80681

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

6шт.

3

564991R91

BEARING

final drive shaft (Fafnir, SKF & New Departure - use w/658006R11 collar)

4шт.

3

592246R91

BEARING

final drive shaft (Fisher - use w/592247R11 collar)

4шт.

4

591862R11

BRACKET, outer brg mounting

2шт.

180077

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

5/16 x 3/4" C-Z type 2

6шт.

80681

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

6шт.

5

591908R11

SUPPORT, 19T drive shaft driven

2шт.

5

596663R11

SPROCKET, 14T drive shaft driven (slow speed)

2шт.

6

313675R1

RING, SNAP,#106, Ext

driven sprocket #106, Ext

2шт.

7

591907R1

SHAFT, final drive

2шт.

8

611902R1

COLLAR

sprocket locking

2шт.

139369

KNIFE SECTION

SCREW, 5/16 x 3/8" hdls cone-pt set

2шт.

9

591905R11

SPROCKET ASSY.

SPROCKET, final drive shaft

2шт.

10

612031R1

FLANGED BEARING

RETAINER, shaft inner brg

4шт.

562336R1

BOLT

W/NUT, 5/16 x 1" C-Z type 2 crg (2-lower)

1шт.

9635884

BOLT,Hex, 5/16" - 18 1", Full Thd, Gr 5

W/NUT, 5/16 x 1" C-Z type 2 (2-upper)

1шт.

80681

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

4шт.

11

594384R1

STRIP, brg retainer wedge

2шт.

180122

BOLT,Hex, 3/8" - 16 x 1", Gr 5

W/NUT, 3/8 x 1" C-Z type 2

2шт.

20803R1

WASHER

13/32 x 1 x 11 ga C-Z

2шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

2шт.

12

CHAIN, final drive upper 5/8" agricultural roller type (for service order 1-1791D 10 ft length of chain, reduce to 51 links & add 1-1315D offset link & 1-1310D connecting link)

2шт.

13

1315D

LINK

drive chain offset

2шт.

14

1310D

LINK

drive chain connecting

2шт.

15

591913R1

EYEBOLT, driver sprocket tightener

4шт.

21763R1

WASHER

15/32 x 3/4 x 11 ga C-Z

4шт.

425-127

SLOTTED NUT,7/16"-14, G5

7/16" C-Z

8шт.

16

20166R1

BOLT,Hex, 5/8" - 11 x 6", Gr 5

W/NUT, 5/8 x 6" C-Z type 2

2шт.

492-11062

BEARING WASHER,5/8"

WASHER, LOCK, 5/8"

2шт.

17

464623R1

WASHER

21/32 x 1-1/2 x 11 ga C-Z

4шт.

18

666624R91

BALL BEARING,16.26mm ID x 40mm OD x 18mm W

driver sprocket (opt w/614640R91 & 611050R91 bearing)

4шт.

18

614640R91

BEARING, driver sprocket (opt w/666624R91 & 611050R91 bearing)

4шт.

18

611050R91

BALL BEARING,0.638" ID x 1.5748" OD x 0.72"

driver sprocket (opt w/666624R91 & 614640R91 bearing)

4шт.

19

133213R91

RING, driver sprocket retaining

4шт.

20

591912R1

BUSHING, driver sprocket

2шт.

21

588564R91

LINK, 1-5/8" chain connecting

2шт.

22

CHAIN, wheel driven sprocket lower 1-5/8" agricultural roller type (for service order 1-606039R91 10 ft length of chain reduce to 31 links & add 588564R91 connecting link)

2шт.

23

591911R1

SPROCKET ASSY.

SPROCKET, 56T wheel drive

2шт.

20166R1

BOLT,Hex, 5/8" - 11 x 6", Gr 5

W/NUT, 5/8 x 6" C-Z type 2

2шт.

492-11062

BEARING WASHER,5/8"

WASHER, LOCK, 5/8"

2шт.

24

591910R1

SPROCKET ASSY.

SPROCKET, 56T wheel drive

2шт.

18710R1

CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 3", Gr 2

BOLT W/NUT, 1/2-NF x 2-3/4" C-Z type 2

8шт.

120384

WASHER,1/2"

LOCK, 1/2"

8шт.

25

CHAIN, final drive intermediate 5/8" agricultural roller type (for service order 1-1791D, 10 ft length of chain reduce to 85 links & add 1-1310D connecting link)

2шт.

26

610538R91

SPROCKET ASSY.

SPROCKET W/BEARING, intermediate chain tightener (opt w/594706R91)

2шт.

26

594706R91

SPROCKET ASSY.,15T

SPROCKET W/BEARING, intermediate chain tightener (opt w/610538R91)

2шт.

426-1040

BOLT,Hex, 5/8" - 11 x 2-1/2", Gr 8

W/NUT, 5/8 x 2-1/2" C-Z type 2

2шт.

464623R1

WASHER

21/32 x 1-1/2 x 11 ga C-Z

4шт.

492-11062

BEARING WASHER,5/8"

WASHER, LOCK, 5/8"

2шт.

27

666624R91

BALL BEARING,16.26mm ID x 40mm OD x 18mm W

sprocket tightener (opt w/611050R91 & 614640R91 bearing)

2шт.

27

611050R91

BALL BEARING,0.638" ID x 1.5748" OD x 0.72"

sprocket tightener (opt w/666624R91 & 614640R91 bearing)

2шт.

27

614640R91

BEARING, sprocket tightener (opt w/666624R91 & 611050R91 bearing)

2шт.

28

613200R91

ADJUSTER, tightener sprocket

1шт.
