Запчасти Case IH 1150 (014) - SHIFTER (14) - MAIN GEARBOX & DRIVE

1

F51085

BEARING

4шт.

2

O697CB

X

COLLAR

4шт.

3

O650CB

X

FLANGE - bearing, drive shafts

4шт.

BOLT - 3/8" x 1" rhd. sq. nk. (11-616) Nut (25-106) L.W. (92-6)

6шт.

4

FH116145

SHAFT - R.H. wheel drive

1шт.

5

FH246249

BRACKET - right shifter pulley mounting

1шт.

BOLT - 3/8" x 2" N.C. hex. full thrd. (113-232) Nut (25-106)

1шт.

6

FHO58859

SPRING

- shifter tension (#8262501 and after)

2шт.

FHO58123

SPRING - shifter tension (Before #8262501)

2шт.

7

FH118307

BRACKET - shifter spring attaching (Before #8262501)

2шт.

8

FH312140

LINK - control (#8262501 and after)

2шт.

NUT - 5/8" N.C. hex. (25-1010)

2шт.

FITTING - grease 1/4"-28 strt. (219-6)

2шт.

BOLT - 3/8" x 2-1/2" N.F. hex. (14-640) Nut (25-116) L.W. (92-6)

2шт.

WASHER - 3/8" flat (95-6)

3шт.

9

FH117085

LINK - end (#8262501 and after)

2шт.

FITTING - grease 1/4"-28 strt. (219-6)

2шт.

BOLT - 3/8" x 3" N.F. hex. (14-644) Nut (25-116) L.W. (92-6)

2шт.

WASHER - 3/8" flat (95-6)

2шт.

FH117036

LINK - adjustable shifter (Before #8262501)

2шт.

10

FHO45021

SPACER - (1-3/16")

2шт.

11

FHO45039

SPACER - (1-9/16")

2шт.

12

FH315861

ARM - shifter, right (#8262501 and after)

1шт.

PIN - cotter 3/16" x 1-1/2" (132-95)

1шт.

FH117176

ARM - right shifter (Before #8262501)

1шт.

13

FH121749

GUIDE - upper shifter belt

2шт.

14

FH159624

SPACER - idler

2шт.

15

FHO53538

PULLEY

- idler

2шт.

BOLT - 1/2" x 3" N.C. hex. (13-848) Nut (25-108) L.W. (92-8)

2шт.

WASHER - 1/2" flat (95-8)

2шт.

16

FH122754

BRACKET - wheel drive belt guide, rear (Before #8262501)

1шт.

17

FH132647

GUIDE - wheel drive belts (Before #8262501)

6шт.

BOLT - 5/16" x 1" rhd. sq. nk. (11-516) Nut (25-105) and L.W. (92-5)

6шт.

18

FH315853

ARM - shifter, left (#8262501 and after)

1шт.

PIN - cotter 3/16" x 1-1/2" (132-95)

1шт.

FH117127

ARM - left shifter (Before #8262501)

1шт.

19

FH116137

SHAFT - L.H. wheel drive

1шт.

20

FH246215

BRACKET - left shifter pulley mounting

1шт.

BOLT - 3/8" x 2" N.C. hex. full thrd. (113-232) Nut (25-106)

1шт.

21

FH222653

PULLEY - driven, right and left hand wheel shaft

2шт.

SCREW - 5/16" x 5/16" N.C. soc. hd. set (83-55)

2шт.

22

FHO56325

BELT

"V" BELT - wheel drive and shifter

2шт.

23

T25070

KEY

- (1/4" x 1/4" x 2"), Serial Range: Pulleys-shaft

2шт.
