Запчасти Case IH 1075 (020) - SHIFTER (14) - MAIN GEARBOX & DRIVE

1

FH246249

BRACKET - shifter R.H.

1шт.

2

F41695

WASHER

BUSHING - mach.

2шт.

3

132-95

COTTER PIN,3/16" x 1 1/2"

Pin, Split (Cotter), 3/16" x 1 1/2"

2шт.

4

219-57

LUBE NIPPLE,90 Degree Elbow, 1/4" - 28 NPTF

FITTING - 1/4"-28 x 90 degree grease

3шт.

5

FH117085

LINK - end

2шт.

6

FH312140

LINK - control

2шт.

7

25-1010

NUT,5/8"-11, G5

2шт.

8

FHO45021

SPACER - 1-3/16" lg.

3шт.

9

FHO45039

SPACER - 1-9/16" lg.

1шт.

10

219-6

LUBE NIPPLE,1/4" - 28 NPTF

FITTING - grease 1/4"-28

4шт.

11

FH246215

BRACKET - shifter L.H.

1шт.

12

F37776

BOLT - 3/8 x 2-1/4" N.C. hex. full thread

1шт.

13

113-213

BOLT,Hex, 3/8" - 16 x 2-1/4", Gr 5

2шт.

25-106

NUT,3/8"-16, G5

- 3/8" N.C. hex.

2шт.

92-6

LOCK WASHER,3/8"

2шт.

95-6

WASHER,3/8"

- flat 3/8"

2шт.

14

F37057

LINK

1шт.

15

FH384727

SPACER - 23/32" lg.

1шт.

16

113-233

BOLT,Hex, 3/8" - 16 x 1-3/4", Gr 5

1шт.

25-106

NUT,3/8"-16, G5

- 3/8" N.C. hex.

1шт.

92-6

LOCK WASHER,3/8"

1шт.

95-6

WASHER,3/8"

- flat 3/8"

3шт.

17

FHO58859

SPRING

2шт.

18

F37062

STOP - shifter

1шт.

19

113-207

BOLT,Hex, 3/8" - 16 x 1", Gr 5

1шт.

20

113-250

BOLT,Hex, 3/8" - 16 x 2-1/2", Gr 5, Full Thd

1шт.

21

FH315853

ARM - shifter L.H.

1шт.

22

113-248

BOLT,Hex, 3/8" - 16 x 2-3/4", Gr 5

1шт.

23

FHO53538

PULLEY

IDLER

2шт.

24

FH159624

SPACER - 1/4" lg.

2шт.

25

FH121749

GUIDE - belt

2шт.

26

111-531

CARRIAGE BOLT,Short NK, 1/2"-13 x 2 3/4", G2

BOLT - 1/2" x 2-3/4" rhd. sq. nk.

2шт.

25-108

NUT,1/2"-13, G5

- 1/2" N.C. hex.

2шт.

92-8

LOCK WASHER,1/2"

2шт.

27

FH315861

ARM - shifter R.H.

1шт.

28

113-241

BOLT,Hex, 3/8" - 16 x 3", Gr 5

1шт.

29

FH222653

SHEAVE

2шт.

30

61-664

BOLT - 3/8" x 4" N.C. hex. socket hd

4шт.

31

83-55

SET SCREW,Hex Soc, 5/16"-18 x 5/16", Cup Pt

2шт.

32

FHO56325

BELT

2шт.
