Артикул
Название
Примечание
Количество
1
86729333
SUPPORT ASSY.
1шт.
2
86979923
HOSE ASSY.
1шт.
3
218-5232
ELBOW,90 Degree, 7/8"-14, 37 Degree x 7/8"-14, 37 Degree Fem Sw
1шт.
4
218-5231
ELBOW,90 Degree, 1 1/16"-12, 37 Degree x 1 1/16"-12, 37 Degree Fem Sw
1шт.
5
86979922
HYDRAULIC HOSE,0.50" ID x 35.00", SAE 100R16
1шт.
Prior To 9/06
1шт.
5
86979920
HOSE ASSY.
1шт.
From 9/06
1шт.
6
86979920
HOSE ASSY.
1шт.
7
87027892
HOSE,1.00" ID x 20.50", SAE 100R4
1шт.
8
87000150
CLAMP,15.869mm ID
1шт.
9
86979915
HOSE,12.70 mm ID x 3378.20 mm, SAE 100R16
1шт.
10
86563609
CLAMP
1шт.
11
87053042
PLATE
2шт.
P.I.N. Y6B41xxxx (01/2007) & After
1шт.
12
87043801
TUBE,19.05 mm OD x 411.3, 107.3 mm L
1шт.
Prior To 9/06
1шт.
12
87379966
HYD TUBE,15.75 mm ID x 19.05 mm OD x 363.2, 105.4 mm L
Tube
1шт.
From 9/06
1шт.
13
0C
ORDER COMPONENTS
Manifold, Independent; Refer To Component Breakdown, Fig. 09.03
1шт.
14
214-1424
HOSE CLAMP,#24, 1.06" - 2", Type F Worm
2шт.
15
617215
MOLDING
72"
1шт.
Cut to fit
1шт.
16
86516805
SOFT TRIM,31-3/4" L
L = 31-3/4"
2шт.
Cut to fit
1шт.
17
87033628
HOSE,0.50" ID x 144.50", SAE 100R6
1шт.
18
218-5106
90 ELBOW,90 Degree Elbow, 3/4" - 16 Male JIC x 3/4" - 16 Male ORB
6шт.
18
237-6008
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
6шт.
19
515-22159
CLAMP,5/8", Insul, 5/16" Bolt
Tube
2шт.
20
261066
ORIFICE,9/16" - 18, 0.813" Orifice
1шт.
21
87017790
HOSE ASSY.
1шт.
22
600427
CLAMP,25.4mm, Coat, 8.7mm Bolt Hole, P Type
1шт.
23
87045897
HOSE,9.65 mm ID x 1346.2 mm, SAE 100R16
1шт.
24
87017791
HOSE ASSY.,9.53mm ID x 2667mm L
1шт.
25
218-5105
ELBOW,90 Degree Elbow, 9/16" - 18 Male JIC x 9/16" - 18 Male ORB
Includes: O-Ring
2шт.
25
237-6006
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
2шт.
26
87029579
ORIFICE
1шт.
27
87011598
PLATE
1шт.
28
87024108
HYDRAULIC CYLINDER
Lift, Refer To Component Breakdown, Fig. 07.12 (1)
1шт.
28
87593870R
REMAN-HYD CYLINDER
WDX1902 (1/05-8/07), WDX2302 (1/05-), Both CASE IH SELF PROPELLED WINDROWER TRACTOR, Lift, Reman for New PN 87024108
1шт.
28
87593870C
CORE-HYD CYLINDER
Return Number
1шт.
28
87593870
HYDRAULIC CYLINDER,Double Acting, 28.7mm Rod, 152.4mm Stroke
Lift, 2" x 6", Refer To Component Breakdown, Fig. 07.12 (2)
1шт.
28
87593870R
REMAN-HYD CYLINDER
WDX1902 (1/05-8/07), WDX2302 (1/05-), Both CASE IH SELF PROPELLED WINDROWER TRACTOR, Lift, 2" x 6"
1шт.
28
87593870C
CORE-HYD CYLINDER
Return Number
1шт.
29
218-5136
ELBOW,45 Degree Elbow, 3/4" - 16 Male JIC x 3/4" - 16 Male ORB
Includes: O-Ring
2шт.
29
237-6008
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
2шт.
30
86979930
HOSE,0.50" ID x 118.00", SAE 100R16
1шт.
31
87017546
HOSE ASSY.
1шт.
32
86979929
HOSE,12.70 mm ID x 1955.80 mm, SAE 100R16
1шт.
33
87046143
SLEEVE
4шт.
35
218-5059
HYD CONNECTOR,3/4"-16, 37 Degree x 3/4"-16, O-Ring
Incl. O-Ring
1шт.
35
237-6008
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
1шт.
36
87011596
MANIFOLD
1шт.
37
214389
PLUG,3/4" - 16 ORB
1шт.
38
87017544
HOSE ASSY.
1шт.
39
218-5070
HYD CONNECTOR,3/4" - 16 Male JIC x 1-1/16" - 12 Male ORB
Includes: O-Ring
2шт.
39
237-6012
O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro
2шт.
40
86979927
HOSE ASSY.
1шт.
41
86566989
CABLE TIE,208mm L
CABLE STRAP
13шт.
42
86513238
LOCK WASHER,.515” ID x 1.070” OD x .120” TK
Belleville, 1/2"
4шт.
44
425-286
FLANGE NUT,Flg, 3/8"-16, G5
7шт.
45
87021824
90 ELBOW,90 Degree, 1 1/16"-12, 37 Degree x 1 5/16"-12, O-Ring
Includes: O-Ring
1шт.
46
425-285
FLANGE NUT,Flg, 5/16"-18, G5
1шт.
47
425-288
FLANGE NUT,Flg, 1/2"-13, G5
4шт.
48
413-652
BOLT,Hex, 3/8" - 16 x 3-1/4", Gr 5
2шт.
49
413-836
BOLT,Hex, 1/2" - 13 x 2-1/4", Gr 5
4шт.
Prior To PIN
1шт.
49
86521614
BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5
4шт.
From PIN
1шт.
50
458-512
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
1шт.
51
413-524
BOLT,Hex, 5/16" - 18 x 1-1/2", Gr 5
1шт.
52
218-5173
ELBOW,45 Degree Elbow, 3/4" - 16 Male JIC x 3/4" - 16 Female JIC
1шт.
53
529070
CABLE TIE,368.3mm L
CABLE STRAP
9шт.
54
86521550
BOLT,Hex, 1/4" - 20 x 3/4", Gr 5
2шт.
55
87044884
SUPPORT
1шт.
56
86624020
FLANGE NUT,Flg, 1/4"-20.G5
2шт.
57
322357
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
2шт.
58
80701
WASHER,0.31" ID x 0.73" OD x 0.07" Thk
2шт.
59
87583054
MTLG PLATE
1шт.
P.I.N. Y6B41xxxx (01/2007) & After
1шт.
60
9707515
BOLT,Hex, 5/16 - 18" x 1 3/4", Gr 5
1шт.
P.I.N. Y6B41xxxx (01/2007) & After
1шт.
