1
86626487
WIRE HARNESS
Console, Includes Ref. 24-33
1шт.
2
86605007
WIRE HARNESS
Cab
1шт.
3
618118
PLUG
2шт.
4
86529089
RELAY
1шт.
5
492-11025
LOCK WASHER,1/4"
1шт.
6
263117
CABLE TIE,292.1mm L, Nylon, Black
CABLE STRAP
3шт.
7
425-285
FLANGE NUT,Flg, 5/16"-18, G5
2шт.
8
86536110
TOGGLE SWITCH
1шт.
9
9845112
COVER
Guard, PTO - Includes: Washer & Nut
2шт.
10
87020409
MODULE
Console, Includes Instructions
1шт.
11
9706732
CLAMP,19mm ID, 8.7mm Bolt Hole, P Type
1шт.
12
86545476
CONSOLE
Top
1шт.
13
641833
IGNITION SWITCH
1шт.
14
86500340
CIGARETTE LIGHTER
1шт.
15
637423
PLUG
1шт.
16
134577
CLIP,J
2шт.
17
86837537
PLUG
1шт.
18
690341
SELF-TAP SCREW
Flg, USR, 5/16"-18 x 5/8"
3шт.
19
490-11012
SCREW,Cross Pan Hd, #10-32 x 3/4"
Machine
4шт.
20
458-512
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
6шт.
21
492-11031
LOCK WASHER,5/16"
6шт.
22
425-104
NUT,1/4"-20, Cl 5
1шт.
23
88826
LOCK NUT,#10-24, GA
4шт.
24
86553678
HYD CONNECTOR
.34-24-23PE
1шт.
25
9623775
FUSE,5 Amp
4шт.
26
9811773
FUSE,10A, Micro, Red
3шт.
27
773464
DIODE
Style 30
1шт.
28
453133C1
PLUG
E18
11шт.
28
225052C1
ELEC. TERMINAL PIN,Male, 0.50 - 1.20 mm2
E18
45шт.
28
280386A1
ELEC CONNECTOR,Nickel, 2.0 - 3.0mm
12-14AWG COPPER NICKEL PLATED
7шт.
29
86553676
ELEC CONNECTOR,Male, 18 - 12 SAE
.34-24-19PE
1шт.
30
86553677
HYD CONNECTOR
.34-24-21PE
1шт.
31
636665
LOCK WASHER,43.18mm ID x 52.68mm OD x 1.57mm Thk
3шт.
32
636666
NUT,1 11/16"-18
3шт.
