Запчасти Case IH WD2104 (29.204.AB[04]) - DRIVE, HYDRAULIC SYSTEM, 6 CYLINDER, HIGH SPEED (29) - HYDROSTATIC DRIVE

1

9840590

O-RING,0.139" Thk x 3.734" ID, -240, Cl 5, 75 Duro

1шт.

2

87313

JAM NUT,Jam, 3/4"-16, G2

2шт.

3

9825943

SENSOR

Magnetic

2шт.

4

87631994

BRAKE ASSY.

Modular

2шт.

5

9706914

O-RING,0.07" Thk x 3.989" ID, -45, Cl 5, 75 Duro

2шт.

6

86512936

ELBOW,9/16" - 18 JIC x 7/16" - 20 ORB

Incl 7

1шт.

7

165202

O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro

1шт.

8

84572611

SHIM

1шт.

9

65319

WASHER,13.1mm ID x 25.4mm OD x 3.68mm Thk

4шт.

10

86513238

LOCK WASHER,.515” ID x 1.070” OD x .120” TK

4шт.

11

47644711

SCREW

, Serial Range: -YGG677045

4шт.

11

47973779

SCREW

, Start Serial: YGG677046

4шт.

Ref 10 Is Not Used With This Screw

1шт.

12

84384

HYD CONNECTOR,9/16"-18, 37 Degree x 7/16"-20, O-Ring

Incl 7

2шт.

13

47615741

TUBE

Motor A Port

1шт.

14

9846955

90 ELBOW,1-7/16"-12 ORFS x 1-5/16"-12 ORB

Incl 15 - 16

4шт.

15

9824050

O-RING,0.07" Thk x 0.926" ID, -21, Cl 6, 90 Duro

4шт.

16

167268

O-RING,0.116" Thk x 1.171" ID, -916, Cl 6, 90 Duro

4шт.

17

84570

90 ELBOW,7/8" - 14 JIC x 1-1/16" - 12 ORB

Incl 18

2шт.

18

167266

O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro

2шт.

19

86502603

COUPLING

4шт.

20

47581891

TEE

4шт.

21

86513011

TEE,37 Degree, 7/8"-14 x 7/8"-14, Fem Sw Run

2шт.

22

384870A1

PLATE

1шт.

23

88275

BOLT,Hex, 5/16" - 18 x 1 1/2", Gr 5

1шт.

24

87603907

CLAMP

1шт.

25

87022336

PLATE

Cover

1шт.

26

87000148

CLAMP

Hydraulic Tube

1шт.

27

322357

BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk

4шт.

28

87405

BOLT,Hex, 1/4" - 20 x 2 1/4", Gr 5

8шт.

29

86900727

COVER

Plate

4шт.

30

87022323

CLAMP,25.4mm D Clamping Pipe

Hydraulic Tube

4шт.

31

9626558

FLANGE NUT,Flg, 1/4"-20

8шт.

32

280112

BOLT,Hex, 1/4" - 20 x 1-1/2", Gr 5

4шт.

33

87000230

PLATE

Cover

1шт.

34

9636711

BOLT,Hex, 5/16 - 18" x 2", Gr 5

1шт.

35

47633871

HYD TUBE

LH, Header Case Drain

1шт.

36

47561737

BRACKET

Ground Drive Tube

1шт.

37

47615740

TUBE

Motor B Port

1шт.

38

47762553

HYD TUBE

LH, Motor Range

1шт.

39

86900725

CLAMP

Twin

1шт.

40

87040663

CLAMP

Hydraulic Tube

1шт.

41

86900726

COVER

Plate

1шт.

42

86513087

FITTING,Blkhd, 9/16"-18, 37 Degree x 9/16"-18, 37 Degree

2шт.

43

47405227

HYD TUBE

LH, Motor Range

1шт.

44

47405226

HYD TUBE

LH, Brake

1шт.

45

47405230

HYD TUBE

LH, Motor Case Drain, Serial Range: -YGG677500

1шт.

45

48000042

TUBE

LH, Motor Case Drain, Start Serial: YGG677501

1шт.

46

86625276

TEE

, Serial Range: -YGG677500

1шт.

46

9610690

FITTING,Blkhd, 7/8"-14, 37 Degree x 7/8"-14, 37 Degree

, Start Serial: YGG677501

1шт.

47

47762644

HYDRAULIC HOSE

LH, Ground Drive

2шт.

48

47762645

HYDRAULIC HOSE

RH, Ground Drive

2шт.
