Запчасти Case IH WD2104 (10.419.AD[01]) - REAR AIR CLEANER DRIVE (10) - ENGINE

1

86548974

FLANGE,Bearing

Drive

2шт.

2

325103

BALL BEARING,25mm ID x 52mm OD x 15mm W

Drive

1шт.

3

87682383

CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 10.9

10шт.

4

322358

BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk

24шт.

5

86507066

FLANGE NUT,M8 x 1.25, Cl 10

26шт.

6

47601612

CHAIN

RC40, Incl 24, Serial Range: -YGG677065

1шт.

6

47972735

CHAIN

RC35, Start Serial: YGG677066

1шт.

7

87598111

DOOR SEAL

Foam

1шт.

8

47463597

BRACKET

Hinge

2шт.

9

87627854

LIGHT ASSY.,12V, 27W, Red

Tail/Stop

2шт.

10

47463758

BRACKET

RAS

2шт.

11

9804256

BOLT,Hex, M6 x 1 x 20mm, Full Thd, Cl 8.8

2шт.

12

322357

BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk

4шт.

13

86050300

FLANGE NUT,M6 x 1.0, Cl 10

7шт.

14

86502967

SCREW,Phillips Drive, Pan HD, M5 x 30mm, Cl 4.8

4шт.

15

322356

BELLEVILLE WASHER,M5 Bolt Size x 12mm OD x 1.85mm Thk

4шт.

16

86507065

NUT,M5 x .8, Cl 10

4шт.

17

87698833

BOLT,M8 x 33.1mm, Cl 10.9

8шт.

18

9804258

BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8

8шт.

19

47691136

PANEL

Coolerbox, Red

1шт.

19

47691141

PANEL

Coolerbox, Yellow

1шт.

20

87736893

HANDLE

RAS Door

1шт.

21

14305821

HEX SOC SCREW,M6 x 40mm, Cl 8.8

2шт.

22

47424119

U-BOLT

Plated

1шт.

23

47668710

STRAP

RAS Pull

1шт.

24

86976086

CONNECTING LINK

Chain, Incl with 6

1шт.
