Запчасти Case IH WD1904 (10.419.AC) - REAR AIR CLEANER ATTACHMENT (10) - ENGINE

1

84603168

LID

Lid, Box

1шт.

2

9804258

BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8

3шт.

3

322358

BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk

5шт.

4

86507066

FLANGE NUT,M8 x 1.25, Cl 10

6шт.

5

47603230

WEIGHT

Lid, Box

1шт.

6

47397192

PIN

Hinge

2шт.

7

9671714

FLANGE BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8

2шт.

8

47662430

STRUT

Gas

2шт.

9

83952214

BALL STUD,M8 x 29.5mm OAL

4шт.

10

9804256

BOLT,Hex, M6 x 1 x 20mm, Full Thd, Cl 8.8

4шт.

11

322357

BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk

4шт.

12

86050300

FLANGE NUT,M6 x 1.0, Cl 10

2шт.
