Запчасти Case IH WD1504 (35.300.AB) - OIL COOLER BOX (35) - HYDRAULIC SYSTEMS

1

47690241

1шт.

2

47524118

OIL COOLER

1шт.

3

47524119

OIL COOLER

Charge Air

1шт.

4

47622501

COOLER ASSY.

1шт.

5

87303266

Foam Bulk

SEAL

1шт.

6

WIC291355

PAD

Ploy Foam

1шт.

7

47591825

SUPPORT

Radiator Seal

1шт.

8

47591826

SUPPORT

Hydraulic Oil Cooler Seal

1шт.

9

47591827

SUPPORT

Charge Air Cooler Seal

1шт.

10

47717291

PANEL

Coolerbox Right

1шт.

11

47717290

PANEL

Coolerbox Left

1шт.

12

9804256

BOLT,Hex, M6 x 1 x 20mm, Full Thd, Cl 8.8

13шт.

13

84570346

ISOLATOR,20mm ID x 53mm OD x 21mm L

Vibration

12шт.

14

9706748

CLAMP,15.9mm, Coat, 8.7mm Bolt Hole, P Type

3шт.

15

87675531

FLANGE BOLT,M6 x 26.6mm, Cl 10.9

3шт.

16

47498859

STRAP

Radiator, Hold Down

1шт.

17

47498860

STRAP

Hydraulic Oil Cooler Hold Down

1шт.

18

47498861

STRAP

Charge Air Cooler Hold Down

1шт.

19

87698835

FLANGE BOLT,M10 x 20mm, Full Thd, Cl 10.9

8шт.

20

140045

BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk

8шт.

21

86050279

FLANGE NUT,M10 x 1.5, Cl 10

8шт.

22

87728300

PIN

Panel Lock

2шт.

23

192216A1

SPRING

Compression

2шт.

24

432-812

COTTER PIN,3/4" OAL x 1/8" W

4шт.

25

86624176

WASHER,11mm ID x 20mm OD x 2mm Thk

4шт.

26

47717127

BUMPER

Rubber

2шт.

27

47606463

FRAME

Condenser

1шт.

28

47515650

COOLER ASSY.

Condenser

1шт.

29

47490207

LATCH

Condenser Frame

1шт.

30

87688487

LATCH ASSY.

Condenser Frame

1шт.

31

47490207

LATCH

Condenser Frame

1шт.

32

87688487

LATCH ASSY.

Condenser Frame

1шт.

33

9804260

BOLT,Hex, M8 x 1.25 x 30mm, Full Thd, Cl 8.8

2шт.

34

322358

BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk

5шт.

35

9804277

FLANGE NUT,Hex, M8 x 1.25, Cl 8

9шт.

36

86507190

CAP

Coolant Recovery

1шт.

37

87698760

FLANGE BOLT,M6 x 36.6mm, Cl 10.9

2шт.

38

87936

BOLT,Hex, 3/8" - 16 x 2 1/2", Gr 5

2шт.

39

86521609

FLANGE NUT,Flg, 3/8"-16

2шт.

40

86511841

BOLT,Flng, M8 x 1.25 x 16mm, Full Thd, Cl 8.8

5шт.

41

87695419

FLANGE BOLT,M8 x 43.1mm, Cl 10.9

4шт.

42

87681210

FLANGE NUT,M8 x 1.25, Cl 10

4шт.

43

140046

BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk

9шт.

44

87695414

BOLT,M12 x 1.25 x 46.8mm, Cl 10.9

8шт.

45

86512497

FLANGE NUT,M12 x 1.75, Cl 10

1шт.

46

290323

HOSE,5/16" ID x 500 FT L, SAE 30R7

Coolant Tank

1шт.

47

574518

HOSE CLAMP,6.3mm - 15.7mm, SAE # 4

Coolant Hose

2шт.

48

86625234

DRAINCOCK/TAP SUPPLY,1/4" NPTF

Drain Fuel Tank

1шт.

49

86507190

CAP

Coolant Recovery

1шт.
