Запчасти Case IH WD2303 (18.23) - HIGH PERFORMANCE LIGHTING KIT, MY2005-2012 RETROFIT (18) - ACCESSORIES

1

84533462

SERVICE KIT

High Performance Lighting, Includes: Ref. 2 - 10 & Installation Instructions

1шт.

2

84360788

WORK LAMP

4шт.

3

84479744

BRACKET

4шт.

4

84488534

WIRE HARNESS

4шт.

5

84488626

WIRE HARNESS

4шт.

6

86511481

FLANGE BOLT,Hex, M8 x 1.25 x 50mm, Cl 8.8

4шт.

7

86050303

NUT

8шт.

8

378243

WASHER,8.4mm ID x 21mm OD x 1.6mm Thk

4шт.

9

308761

CARRIAGE BOLT,M8 x 1.25 x 25mm, Cl 8.8

4шт.

10

322358

BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk

8шт.

11

263117

CABLE TIE,292.1mm L, Nylon, Black

CABLE STRAP

4шт.

12

9609150

MISC PACKAGING

1шт.

13

84485188

BRACKET

Can be ordered as optional kit components

1шт.

14

84496255

WORK LAMP

Can be ordered as optional kit components

1шт.

15

84488536

WIRE HARNESS

Can be ordered as optional kit components

1шт.
