Запчасти Case IH WD1903 (06.08[2.1]) - ELECTRICAL, CAB, FROM YCG667001 (06) - ELECTRICAL

1

84515752

WIRE HARNESS

Main CM 4, Non-Draper Option. For Serviced Components: See Ref. 34-48

1шт.

2

84515756

WIRE HARNESS

Main CD 4, Factory Draper Option. For Serviced Components: See Ref. 34-46

1шт.

3

323597

CABLE TIE,165mm OAL x 9mm Thk

4шт.

4

86705351

RESISTOR

1шт.

5

9832203

HEX SOC SCREW,M6 x 25mm, Cl 8.8, Full Thd

12шт.

6

48917

WASHER

2шт.

7

87040922

SELF-TAP SCREW,Washer Hd, #12-24 x 5/8"

4шт.

8

86016585

SCREW,Phil Pan Hd, M6 x 20mm, Cl 4.8

5шт.

9

86639138

SELF-TAP SCREW,HWH, M4.8 x 1.6 x 13mm

3шт.

10

412064

BOLT,Hex, M4 x 16mm, Cl 8.8, Full Thd

2шт.

11

120103

BOLT,M8 x 1.25 x 16mm, Cl 8.8

1шт.

12

120104

BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8

3шт.

13

280523

BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5

M6 x 20

1шт.

14

140045

BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk

Self-Tapping, HWH, M4 x .7 x 16

1шт.

15

322358

BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk

2шт.

16

322355

BELLEVILLE WASHER,M4 Bolt Size x 10mm OD x 0.9mm Thk

5шт.

17

322357

BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk

17шт.

18

9635082

NUT,5/16" - 18, Gr 5

2шт.

19

100012

NUT,M4 x 0.7, Cl 8

1шт.

20

86521609

FLANGE NUT,Flg, 3/8"-16

1шт.

21

87035431

GROUND STRAP

1шт.

22

9811773

FUSE,10A, Micro, Red

Not Illustrated

5шт.

23

87389483

FUSE

40 AMP, Not Illustrated

1шт.

24

9623775

FUSE,5 Amp

Not Illustrated

7шт.

25

9804895

FUSE,20A, Micro, Yellow

Not Illustrated

5шт.

26

84090658

FUSE,Lt Blue, 15 Amp

Not Illustrated

1шт.

27

86537972

RELAY

Relay, A 332 202 544, Bosch, Not Illustrated

5шт.

28

9623776

FUSE,7.5A, Micro, Brown

Not Illustrated

14шт.

29

86509590

RELAY

Micro, Module, Not Illustrated

18шт.

30

774735

DIODE,6A

Style 30, 6 AMP, Not Illustrated

1шт.

31

87040745

AUTOM.CIRCUITBREAKER

Bussmann, 50 AMP, Not Illustrated

3-Aprшт.

32

86610929

CIRCUIT BREAKER

15 AMP, Not Illustrated

1шт.

33

87022597

MODULE

Diode, Not Illustrated

1шт.

34

87589225

FUSE,70A

70 AMP, Not Illustrated

1шт.

35

368459A1

RELAY,12V, 70A

70 AMP (Blower), Not Illustrated

1шт.
