Артикул
Название
Примечание
Количество
1
87628438
SUPPORT
1шт.
2
87738255
HOSE
Attaches to Ref. 46
1шт.
3
87573354
HOSE
Attach to "P1" Port of Ref. 46 & Header Lift Pump
1шт.
4
87041669
HOSE ASSY.
Attach to "HL" Port of Ref. 46, Non-Draper Option
1шт.
5
87046143
SLEEVE
4шт.
6
87585689
HOSE
Attach to "P5" Port of Ref. 46
1шт.
7
86979915
HOSE,12.70 mm ID x 3378.20 mm, SAE 100R16
Non-Draper Option
1шт.
8
87612414
HOSE
Attach to "RD" Port of Ref. 46
1шт.
9
87301358
HOSE CLAMP,1.00/1.875 HD Worm
2шт.
10
86563609
CLAMP
1шт.
11
87053042
PLATE
2шт.
12
87679334
SUPPORT
1шт.
13
529070
CABLE TIE,368.3mm L
CABLE STRAP
9шт.
14
87383612
ACCUMULATOR
1шт.
15
772028
CLIP
1шт.
16
87033603
HOSE ASSY.
1шт.
17
87017787
HOSE ASSY.
Attach to "ACC" Port of Ref. 46
1шт.
19
600427
CLAMP,25.4mm, Coat, 8.7mm Bolt Hole, P Type
1шт.
20
261066
ORIFICE,9/16" - 18, 0.813" Orifice
1шт.
21
87017790
HOSE ASSY.
Attach to "P3" Port of Ref. 46
1шт.
22
129172
CLAMP
2шт.
23
9706748
CLAMP,15.9mm, Coat, 8.7mm Bolt Hole, P Type
2шт.
24
87017791
HOSE ASSY.,9.53mm ID x 2667mm L
1шт.
25
76344
90 ELBOW,9/16" - 18 JIC x 9/16" - 18 ORB
2шт.
26
87029579
ORIFICE
1шт.
27
87011598
PLATE
1шт.
28
87593870
HYDRAULIC CYLINDER,Double Acting, 28.7mm Rod, 152.4mm Stroke
Header Tilt, 2" x 6"
1шт.
28
87593870R
REMAN-HYD CYLINDER
WD1203, WD1903, WD2303, All CASE IH SELF-PROPELLED WINDROWER, Header Tilt, 2" x 6" (9/07-)
1шт.
28
87593870C
CORE-HYD CYLINDER
Return Number
1шт.
28
84316402
HYDRAULIC CYLINDER,Double Acting, 28.57mm Rod, 101.6mm Stroke
Header Tilt, 2" x 4"
1шт.
29
216797
45 ELBOW,45 Degree, 3/4"-16, 37 Degree x 3/4"-16, O-Ring
2шт.
30
87041664
HOSE,0.50" ID x 61.00", SAE 100R6
Attach to "LD" Port of Ref. 46
1шт.
31
87041666
HOSE ASSY.
Non-Draper Option
1шт.
32
87000150
CLAMP,15.869mm ID
1шт.
33
86511870
TEE,3/4" - 16 JIC x 3/4" - 16 JIC x 3/4" - 16 JIC
1шт.
34
87583054
MTLG PLATE
1шт.
36
87011596
MANIFOLD
1шт.
37
214389
PLUG,3/4" - 16 ORB
1шт.
38
87591631
ROD
Used With 2" x 6" Cyl.
1шт.
Plate On End; Secured By Bolts
1шт.
38
84316776
ROD
Used With 2" x 4" Cyl, TY2011
1шт.
39
87604521
CYLINDER BLOCK
Used With 2" x 6" Cyl.
2шт.
40
87020604
DECAL
Indicator, 6-5-4-3-2-1
1шт.
40
84298481
DECAL
Tilt Indicator, 0-4
1шт.
41
86566989
CABLE TIE,208mm L
CABLE STRAP
12шт.
42
86521613
BOLT,Hex, 3/8" - 16 x 1", Gr 5
1шт.
43
248992
45 ELBOW,45 Degree, 3/4"-16, 37 Degree x 3/4"-16, 37 Degree Fem Sw
1шт.
44
87583345
ORIFICE
1шт.
45
87518211
HOSE ASSY.
Attach to "HL" Port of Ref. 46, Draper Option
1шт.
46
0C
ORDER COMPONENTS
Deluxe Manifold, Non Draper Option
1шт.
Components Can Be Found on Fig. 09.09(1)
1шт.
47
9707515
BOLT,Hex, 5/16 - 18" x 1 3/4", Gr 5
1шт.
48
88346
BOLT,Hex, 5/16" - 18 x 2 1/2", Gr 5
1шт.
49
280523
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5
2" x 6" Cylinder Only
2шт.
50
0C
ORDER COMPONENTS
Deluxe Manifold, Draper Option
1шт.
Components Can Be Found on Fig. 09.09(2)
1шт.
51
680242
FLEXIBLE HOSE
1шт.
52
87626
BOLT,Hex, 5/16" - 18 x 2 3/4", Gr 5
2шт.
53
80664
WASHER,0.38" ID x 0.88" OD x 0.08" Thk
2шт.
54
86521552
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
2шт.
56
86513238
LOCK WASHER,.515” ID x 1.070” OD x .120” TK
Belleville, 1/2"
4шт.
57
322357
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
2шт.
58
80701
WASHER,0.31" ID x 0.73" OD x 0.07" Thk
2шт.
60
86521606
FLANGE NUT,Hex, 3/8" - 16, Gr 5
8шт.
61
86624020
FLANGE NUT,Flg, 1/4"-20.G5
2шт.
62
86521607
FLANGE NUT,Flg, 1/2"-13, G5
4шт.
63
86521605
FLANGE NUT,5/16"-18, Cl 5
3шт.
65
9637240
BOLT,Hex, 3/8" - 16 x 3 1/4", Gr 5
2шт.
67
86521550
BOLT,Hex, 1/4" - 20 x 3/4", Gr 5
2шт.
70
86512388
CLAMP,19.05mm ID, 10.41mm Bolt Hole, P Type
1шт.
71
86508771
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 1 3/4", Gr 5
1шт.
72
87478157
TUBE ASSY.
Attach to Port "TI" of Ref. 46 & "AUX" Port on Reservoir
1шт.
P.I.N. Y8G661152 & After
1шт.
Выбрано товаров: 78
