Запчасти Case IH 8870 (08-10) - HYDRAULIC CYLINDER ASSEMBLY (TWO SPEED SHIFT) (35) - HYDRAULIC SYSTEMS

Схема запчастей Case IH 8870 - (08-10) - HYDRAULIC CYLINDER ASSEMBLY (TWO SPEED SHIFT) (35) - HYDRAULIC SYSTEMS
1
3
4
2

Артикул

Название

Примечание

Количество

7075625

CYLINDER

ASSEMBLY hydraulic, complete, 2" bore by 4" stroke

1шт.

1

7732241

HEAD

cylinder

1шт.

2

7732266

ROD

ASSEMBLY piston

1шт.

3

7732258

TUBE ASSY.

BARREL

1шт.

4

7732274

SEAL KIT

KIT

1шт.

Выбрано товаров: 5
