Запчасти Case IH 8870 (07-72) - REAR WHEEL ASSEMBLY - RIGHT (27) - REAR AXLE SYSTEM

1

7852866

BUSHING

machinery, narrow rim, 2" x 18 gauge

2шт.

2

52548

SPECIAL WASHER

BUSHING machinery, narrow rim, 2" x 14 gauge

2шт.

3

700134096

BEAM

WA wheel, tail

1шт.

4

219-8

LUBE NIPPLE,1/4" - 28 NPTF

2шт.

5

852491

BRONZE BUSHING

BRONZE BUSH

2шт.

6

700152419

PIN

ASSEMBLY

2шт.

7

705574

WASHER,1 1/8" x 2" x .156", HDN

2шт.

8

232-41116

LOCK NUT,1"-8, GC

2шт.

9

700134109

FORK

WA

1шт.

10

6268841

WASHER

1шт.

11

413-1232

BOLT,Hex, 3/4" - 10 x 2", Gr 5

1шт.

12

425-1412

JAM NUT,Jam, 3/4"-10, G5

HJN, 3/4"-10, grade 2

1шт.

13

700718489

BRONZE BUSHING

2шт.

Part of Rear Axle Ref. 17 P/N 700130901

1шт.

14

103-11225

SNAP RING,#225, Ext

1шт.

15

700147338

SHAFT

pivot

1шт.

16

852947

BUSHING

machinery, narrow rim, 2-1/4" x 14 gauge

2шт.

17

700130901

AXLE

WA rear, Includes: Ref. 13

1шт.

18

700134128

BUSHING

1шт.

19

61-35052

HEX SOC SCREW,1/2"-13 x 3 1/4"

cap, hex socket head, 1/2"-13 x 3-1/4"

2шт.

20

231-5348

FLANGE NUT,Flg, 1/2"-13

lock, hex flange top, GR/G, 1/2"-13

2шт.

21

433-512

CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5

4шт.

22

232-5315

FLANGE NUT,Flg, 5/16"-18

lock, hex flange top, GR/G, 5/16"-18

4шт.

23

700134125

RAIL

hand, WA

1шт.

24

700711334

FASTENER

push on

4шт.
