Запчасти Case IH 8870 (06-06) - PLANETARY GEAR ASSEMBLY (90) - PLATFORM, CAB, BODYWORK AND DECALS

700715356

GEAR

ASSEMBLY planetary

1шт.

1

700717100

BOLT

SCREW cap, hex, 3/8"-16 x 4-1/2"

12шт.

2

700717101

WASHER

flat

12шт.

3

700716990

SHAFT

input

1шт.

4

700716986

SEAL

oil

1шт.

5

700716987

BEARING

cylindrical

1шт.

6

700716988

BEARING

cylindrical

1шт.

7

700716989

RING

retaining, external

1шт.

8

700716979

GEAR

sun

1шт.

9

700716981

CARRIER ASSY.

1шт.

10

700716978

NUT

lock

1шт.

11

700715785

WASHER

lock

1шт.

12

700716980

WASHER

thrust

1шт.

13

700715782

PLUG

magnetic

1шт.

14

700715781

SEAL

oil

1шт.

15

700715784

BEARING, CONE

1шт.

16

700715783

BEARING, CUP

1шт.

17

700715786

PLUG

magnetic

3шт.

18

700715787

BEARING

CUP

1шт.

19

700715788

BEARING

CONE

1шт.

20

700716982

TOOL

locknut, bearing

1шт.

21

700716983

TOOL

DRIVER bearing cone

1шт.

22

700716984

TOOL

drive, spindle/shaft

1шт.
