Запчасти Case IH 8840 (04-012) - ENGINE WIRING ASSEMBLY (STARTER/ALTERNATOR) (55) - ELECTRICAL SYSTEMS

1

700705183

HEADLAMP

flood

2шт.

2

700705124

WIRE

electrical

2шт.

3

721878

CLIP

wire

2шт.

4

306132C1

CABLE TIE,14.5" L

CABLE STRAP TIE

3шт.

5

700708220

SWITCH

pressure

1шт.

6

700712181

HYDRAULIC HOSE,6.35 mm ID x 125.00 mm, TYPE 100R2 SAE J517

1шт.

7

1341329C1

TRANSMITTER

SENDER oil pressure

1шт.

8

8025637

SWITCH

2шт.

9

515-25127

CLAMP,1/2", Insul, 1/2" Bolt

Line

3шт.

10

7027352

RUBBER

GROMMET

1шт.

11

121-115

SERRATED BOLT,Hex, 5/16" - 18 x 3/4"

6шт.

12

231-5145

SERRATED NUT,Flg, USR, 5/16"-18

6шт.

13

217-1032

ADAPTER,1/8" - 27 NPT x 1/8" - 27 NPT

ADAPTER

2шт.

14

7745193

CLIP

wire

2шт.

15

700707298

SENDER UNIT

UNIT

1шт.

16

700710290

LAMP, TAIL

LIGHT, TAIL

1шт.
