Запчасти Case IH 8820 (8-04) - HYDRAULIC RESERVOIR ASSEMBLY (CONTINUED) (08) - HYDRAULICS

1

7037799

O-RING,14-1, 90 Duro, 1.048" ID x .116" Thk

2шт.

2

8046864

FITTING

90deg. Barbed Insert (Includes Item 1)

2шт.

3

7022411

HOSE CLAMP

Clamp - Hose

8шт.

4

7724347

STRAP

Tie - Nylon

3шт.

5

8842999

HOSE

- Hydraulic

2шт.

6

8046971

STEM

Tee - Barbed Insert

1шт.

7

738484

O-RING

2шт.

8

7846587

ELBOW

90deg. Barbed Insert (Includes Item 7)

1шт.

9

700706203

FLEXIBLE HOSE

Hose - Hydraulic

1шт.

10

700705542

SEAL KIT

Hose - Hydraulic

1шт.

11

8746521

REDUCER

(Includes Item 15)

1шт.

12

700705119

REDUCER

(Includes Item 7)

1шт.

13

8046518

TEE

(Includes Item 14)

1шт.

14

279706

O-RING

1шт.

15

7037807

O-RING,20-1, 90 Duro, 1.475" ID x .116" Thk

1шт.
