Запчасти Case IH WRX301 (55.404.01) - ELECTRICAL, LIGHT KIT (55) - ELECTRICAL SYSTEMS

1

86630736

SUPPORT ASSY.

2шт.

2

86624454

LAMP

Amber

2шт.

3

853709

GASKET,1.65mm Thk

4шт.

4

86622240

LENS

Amber

4шт.

5

A41264

BULB,#1156, 12V

1шт.

6

86621619

WARNING LIGHT

Red

2шт.

7

T34857

BULB,C6, #1157, 12.8V

1шт.

8

86622241

LENS

Red

1шт.

9

853709

GASKET,1.65mm Thk

2шт.

10

495-21056

WASHER,1/2"

2шт.

11

80679

LOCK WASHER,1/20.507 CST ZND

2шт.

12

425-118

NUT,1/2"-20, G5

2шт.

13

458-616

BOLT,Hex Flg, 3/8" - 16 x 1", Gr 5

4шт.

14

140045

BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk

4шт.

15

425-286

FLANGE NUT,Flg, 3/8"-16, G5

4шт.

16

86598388

PAD

2шт.

17

425-104

NUT,1/4"-20, Cl 5

2шт.

18

86643199

WIRE HARNESS

Rear

1шт.

19

86643198

WIRE HARNESS

Front

1шт.

20

86643200

WIRE HARNESS

Lights

1шт.

21

322357

BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk

4шт.

22

87034857

COVER

Module Protection

1шт.

23

86561136

MODULE

Control

1шт.

24

458-412

BOLT,Hex, 1/4" - 20 x 3/4", Gr 5

8шт.

25

86515458

WASHER,13mm ID x 22.22mm OD x 1.62mm Thk

M12.7

2шт.

26

231-5344

FLANGE NUT,Flg, 1/4"-20

4шт.

27

9611467

HOLDER

Plug Holder

1шт.

28

529070

CABLE TIE,368.3mm L

CABLE STRAP

25шт.

29

87020263

KIT

Lights, 12 Wheel

1шт.

29

87020267

KIT

Lights, 14 - 20 Wheel

1шт.
