Запчасти Case IH VARIOUS (D-28) - REAR AXLE ASSY

Схема запчастей Case IH VARIOUS - (D-28) - REAR AXLE ASSY

Артикул

Название

Примечание

Количество

1

56029C91

AXLE ASSY, rear, Includes ref. nos. 2, 3, 4, 8 and attaching hardware, Wagons w/serial no. 2123 and below

1шт.

1

61799C91

AXLE ASSY, rear, Replaces 60056C91, Includes ref. nos. 2, 3, 4 and 8, Wagons w/serial no. 2124 and above

1шт.

18804R1

BOLT,Hex, 7/16"-14 x 4", G2

7/16 x 4 type 1

4шт.

271500

SOCKET

7/16-14 hex.

4шт.

3

55936C1

WASHER

spindle

2шт.

4

427645

SLOTTED NUT,7/8"-14, G5

NUT, 7/8-14 slt hex.

2шт.

103397

COTTER PIN,5/32" x 1 1/4"

Pin, Split (Cotter), 5/32" x 1 1/4"

2шт.

5

55925C1

REACH, 81 in. outer

1шт.

5

55926C1

REACH, outer extension, For 12 ft to 15 ft wheel base

1шт.

17721R1

BOLT, 1/2 x 4 hex-hd mach

2шт.

103323

LOCK WASHER,1/2"

WASHER, LOCK, 1/2"

2шт.

9413956

LOCK NUT,1/2"-13, GB

NUT, 1/2-13 hex. lock

2шт.

6

56835C1

COLLAR, reach

2шт.

17721R1

BOLT, 1/2 x 4 hex-hd mach

2шт.

103323

LOCK WASHER,1/2"

WASHER, LOCK, 1/2"

1шт.

9413956

LOCK NUT,1/2"-13, GB

NUT, 1/2-13 hex. lock

2шт.

7

56836C1

REACH, pipe inner

1шт.

17699R1

BOLT,Hex, 1/2" - 13 x 3 3/4"

1/2 x 3-3/4 hex-hd mach

1шт.

103323

LOCK WASHER,1/2"

WASHER, LOCK, 1/2"

1шт.

9413956

LOCK NUT,1/2"-13, GB

NUT, 1/2-13 hex. lock

1шт.

8

59314C91

SPINDLE ASSY, rear, Includes ref. nos. 3 and 4, Wagons w/serial no. 2123 and below

1шт.

Выбрано товаров: 21
