Запчасти Case IH VARIOUS (D-05[1]) - REAR AXLE ASSY

1

55788C91

AXLE ASSY, rear, Composed of:

1шт.

271500

SOCKET

4шт.

427639

SLOTTED NUT,3/4"-16, G5

NUT

2шт.

103397

COTTER PIN,5/32" x 1 1/4"

Pin, Split (Cotter), 5/32" x 1 1/4"

2шт.

179874

BOLT,Hex, 7/16" - 14 x 4", Gr 5

4шт.

55626C1

WASHER

2шт.

179874

BOLT,Hex, 7/16" - 14 x 4", Gr 5

4шт.

NLS

NO LONGER SERVICED

7/16-14 hex.

4шт.

427639

SLOTTED NUT,3/4"-16, G5

NUT

2шт.

103397

COTTER PIN,5/32" x 1 1/4"

Pin, Split (Cotter), 5/32" x 1 1/4"

2шт.

55656C1

WASHER

2шт.

4

55626C1

WASHER, spindle

2шт.

5

427639

SLOTTED NUT,3/4"-16, G5

NUT, 3/4-16 slt hex.

2шт.

103397

COTTER PIN,5/32" x 1 1/4"

Pin, Split (Cotter), 5/32" x 1 1/4"

2шт.

6

55790C1

REACH, outer

1шт.

179893

BOLT,Hex, 1/2" - 13 x 3", Gr 5

SCREW, 1/2-13 x 3 hex-hd cap

1шт.

179895

BOLT,Hex, 1/2" - 13 x 3 1/2", Gr 5

SCREW, 1/2-13 x 3-1/2 hex-hd cap

2шт.

9413956

LOCK NUT,1/2"-13, GB

NUT, 1/2-13 hex. lock

3шт.
