Запчасти Case IH 1200 (L-11[A]) - HYDRAULIC EQUIPMENT

371291R95

CYLINDER

ASSY, 2-1/2 x 8 in. double acting hydraulic, order cylinder assy, 145353C91, two adapters, 1252129C1 and two o-rings 570828R1, for components see list of parts under details of hydraulic cylinders in section P

1шт.

371292R94

CYLINDER

ASSY, 3-1/2 x 8 in. double acting hydraulic, order assy, 1263474C91, two adapters, 1252129C1 and two o-rings, 570828R1, for components see list of parts under details of hydraulic cylinders in section P

1шт.

381832R93

CYLINDER BLOCK

CYLINDER ASSY, 2 x 8 in. single acting hydraulic, order cylinder assy, 381833R93, for components see list of parts under details of hydraulic cylinder in section P

1шт.

381833R93

CYLINDER ASSY.

CYLINDER ASSY, 2 x 8 i. double acting hydraulic, for components see list of parts under details of hydraulic cylinder in section P

1шт.

1272850C1

ADAPTER

ADPATER, o-ring boss, use to adapt 7/8-14 hose fitting to 3/4-16 coupling

1шт.

106671

LUBE NIPPLE,1/8"-27 NPT x .50" lg, Press Relief

VALVE, 1/8-27 pts short press relief, use with 3/4-16 straight thread

1шт.

364885R1

O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro

5/8 OD tube class 6, for adapter, 1272850C1

1шт.

145353C91

HYDRAULIC CYLINDER

CYLINDER ASSY, 2-1/2 x 8 in. double acting hydraulic, for components see list of parts under details of hydraulic cylinder in section P

1шт.

1252129C1

ADAPTER,7/8" - 14 ORB x 3/4" - 16 ORB

ADAPTER, 7/8-14 female x 3/4-16 male o-ring boss

2шт.

570828R1

O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro

1/2 OD tube class 6

2шт.

1263474C91

CYLINDER ASSY.

CYLINDER ASSY, 3-1/2 x 8 in. double acting hydraulic, for components see list of parts under details of hydraulic cylinder in section P

1шт.

1252129C1

ADAPTER,7/8" - 14 ORB x 3/4" - 16 ORB

ADAPTER, 7/8-14 female x 3/4-16 male o-ring boss

2шт.

570828R1

O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro

1/2 OD tube class 6

2шт.

461166R91

HOSE ASSY.

HOSE ASSY, 1/2 x 100 in. hydraulic

1шт.

395149R1

QUICK MALE COUPLING

COUPLING, 7/8-14 str thd self-sealing male half, poppet type or

1шт.

1272399C1

UNION

COUPLING, 7/8-14 str thd self-sealing male half, ISO standard or

1шт.

544787R91

COUPLING, BREAK AWAY

COUPLING, 7/8-14 str thd self-sealing male half, ball type or

1шт.

1285718C1

COUPLING

3/4-16 str thd self-sealing male half, ISO standard

1шт.

364885R1

O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro

5/8 OD tube class 6

3шт.

60836H

BREATHER

for double acting hydraulic cylinders

1шт.
